Code Blue Z11782-05 CB 2-a Help Point Wall Mount

Overview

The Z11782-05 is a wall-mount enclosure for the Code Blue CB 2-a Series Help Point — the fixed-wall alternative to a pedestal install for indoor and outdoor emergency communication points along building exteriors, parking structures, and campus corridors where floor space or footing depth rules out a freestanding pole. It's built to a custom finish (PMS 7409C WU Gold) for installs where matching a facility's color standard matters, and it houses the beacon/strobe and speakerphone electronics behind a 0.078-inch stainless steel shell — thick enough to resist dents and pry attempts in high-traffic public areas without adding excess wall load.

Compatibility

The Z11782-05 is built for the Code Blue 2 Series Analog Help Point family and accepts the LS1000 VoIP Speakerphone or the IA4100 Analog Speakerphone — confirm which speakerphone your system specifies before ordering, since the wiring and power draw differ between VoIP and analog units. The integrated beacon/strobe ships as a standard feature, so no separate light module is needed for visual alert compliance.

Installation Notes

Power input is 12-24V AC/DC, matching typical Help Point low-voltage runs — verify your power source falls in that window before terminating at the unit to avoid under- or over-driving the strobe and speakerphone. The enclosure is Built to NEMA 4, so it holds up against outdoor wash-down, wind-driven rain, and dust on exterior wall mounts, and it's Designed to ADA Specifications, which matters for reach-range and operable-part height compliance on any publicly accessible install. At 25 lbs. and 29.79in H x 11.90in W x 4in D, plan for solid wall-anchor points — this is not a lightweight bracket, and standard drywall anchors won't hold it. The unit carries UL 62368-1 compliance for the electronics inside. As a Custom/Special Order finish item, lead times typically run longer than stocked Code Blue finishes, so factor that into project scheduling.
