Code Blue CB2E00360 Wall-Mount PoE Unit
Overview
The Code Blue CB2E00360 is an IP68-rated wall-mounted enclosure designed to house and protect security hardware in wet, dusty, and corrosive environments. Powered via standard PoE (802.3af), it draws under 13W, eliminating the need for auxiliary power runs to remote perimeter locations. The brushed stainless steel construction handles salt spray, rain, and industrial spray without corrosion — a critical advantage on utility poles, loading docks, and coastal installations where galvanized or painted steel fails within months.
Compatibility
The CB2E00360 integrates with any PoE-enabled network infrastructure compliant with IEEE 802.3af (switches, injectors, and standard PoE+ midspans). It is designed to house surveillance and access control equipment requiring sealed, outdoor-rated enclosures. Wall mounting supports flexible placement in perimeter security, building access points, and outdoor telecom installations. Verify internal cavity dimensions and cable entry points against your specific payload (camera, control module, or sensor assembly) before ordering — the housing is generic by design and requires site-specific wiring planning.
Installation Notes
IP68 rating applies only when cable glands and entry points are properly sealed with weatherproof connectors (sold separately). Do not rely on the enclosure rating alone if conduit or bare wiring is exposed. Wall mounting requires structural fasteners rated for your substrate (wood, masonry, or steel) — concrete anchors are not included. Plan PoE cable management: 802.3af sources deliver ~13W usable power after voltage drop, so high-current payloads (industrial PTZ or multi-sensor arrays) will require PoE+ or a separate supply inside the unit. Test power delivery at the installation site before final deployment.
What's in the Box
- 1x Code Blue CB2E00360 IP68 wall-mount enclosure
