Code Blue CB2A00041 Wall-Mount Help Point Push Button
Overview
The Code Blue CB2A00041 is a wall-mounted emergency help point designed for outdoor and entryway installations where property owners need hands-free emergency communication with visual alerting. The unit combines a push-button interface with a high-intensity LED beacon and strobe lights that signal distress across parking decks, transit centers, and building entrances. Two-piece brushed stainless steel construction keeps weight at 25 lb, making single-person installation feasible without structural reinforcement. ADA-compliant profile (29.8" H × 11.9" W × 4" D) fits within accessibility reach requirements.
Compatibility
The CB2A00041 operates on either 12V DC or 24V DC input, making it compatible with standard security power supplies and monitored electrical panels common in access control and perimeter monitoring systems. The unit integrates into hardwired emergency communication networks rather than IP-based systems — it does not require PoE or network connectivity. Suitable for standalone deployment or integration with analog CCTV and access control infrastructure using traditional 24V DC emergency power distribution.
Installation Notes
NEMA 3S rating protects against corrosion and rain exposure but does not provide submersion protection — install on covered walls or under eaves to avoid standing water. Input voltage (12V or 24V DC) must be supplied via dedicated emergency power circuit; confirm power supply amperage before mounting. Two-piece design allows faceplate removal for internal wiring without tool damage. Stainless steel fasteners prevent rust in salt-air or high-humidity environments.
What's in the Box
- 1x CB2A00041 Help Point assembly (two-piece stainless steel housing)
- Mounting template
