Code Blue CB1S00646 Dual Faceplate PoE Module
Overview
The CB1S00646 is a dual-faceplate configuration for the Code Blue CB1-s Help Point tower (1 Series Surface), pairing two illuminated call faceplates on a single PoE-powered pedestal. It fits deployments where one tower needs to serve two call functions or two directions of approach — parking structures, transit platforms, and campus paths where a single-faceplate unit would force a second pole. Each faceplate integrates the LED ring light and beacon/strobe so the unit stays visible at night and signals an active call, which matters for compliance walkthroughs and for anyone approaching the tower from either side.
Compatibility
Built for the CB1-s Help Point family (1 Series Surface) and wired for PoE at 12-24V AC/DC input, so it runs off standard PoE injectors or PoE switch ports without a dedicated AC drop at the pole. Configure each faceplate with an LS1000 VoIP Speakerphone, LS2000 VoIP Handset, or IA4100 Analog Speakerphone (analog full-duplex) — mix or match per faceplate depending on whether the site runs VoIP or an analog paging/phone backbone. Confirm your call system matches one of these three before ordering, since the faceplate electronics are matched to the speakerphone type.
Installation Notes
The tower body is 0.135" (10-gauge) steel, rated to UL 62368-1 and built to NEMA 3 for outdoor exposure, with dimensions to ADA specifications — relevant for any path-of-travel installation where reach range and clear floor space get inspected. At 108" (274.32 cm) tall, 12.75" (32.38 cm) in diameter, and 210 lbs (95.25 kg), plan for a concrete footing and hardware rated for that mass rather than a surface-bolt install on asphalt. Route PoE cabling to each faceplate's parallel connection point during rough-in, since both faceplates draw from the same tower base.
