Code Blue CB1S00436 PoE Cable Connector

Overview

The Code Blue CB1S00436 is an IP68-rated PoE cable connector designed to consolidate power and data delivery into a single weather-sealed connection point for outdoor and vandal-prone security deployments. This accessory integrates 802.3af PoE input, eliminating the need for separate power and signal runs to field-mounted cameras, access control devices, and network equipment in wet, dusty, or high-humidity environments. The IP68 rating means it handles full submersion and sustained harsh field conditions — relevant if you're installing in perimeter security arrays, industrial facilities, or coastal environments where salt spray and standing water are normal.

Compatibility

The CB1S00436 works with IP-based camera systems, access control readers, and outdoor network equipment that accept standard PoE input via RJ-45 or equivalent connectors. It is compatible with Code Blue's speakerphone and intercom ecosystems, including the LS1000 VoIP Speakerphone, LS2000 VoIP Handset, and IA4100 Analog Speakerphone configurations. Verify that your device's PoE input specification matches 802.3af delivery (13W maximum); devices requiring PoE+ (802.3at, 25.5W) or higher will not function reliably with this connector. For integrations outside the Code Blue family, confirm RJ-45 pinout and voltage compatibility with the target device's datasheet before ordering.

Installation Notes

The IP68 rating requires intact seals during termination. Inspect the connector housing and gaskets for damage before installation. Secure all cable entries and ensure strain relief is in place to prevent water ingress at the termination point. The connector is designed for outdoor mounting; avoid direct mechanical stress or sharp bends near the connector body. Test the connection with a multimeter after installation to verify continuity and polarity before powering the downstream device. Keep the connector cap closed when not in use to maintain the IP68 seal.
