Description

StarTech TB3DOCK2DPPD Thunderbolt 3 Docking Station

Overview

The StarTech TB3DOCK2DPPD is a Thunderbolt 3 docking station designed to expand the capabilities of a Thunderbolt 3-equipped laptop. It provides a single-cable solution for connecting multiple peripherals, external displays, and wired networks, while also delivering up to 85W of power for laptop charging. This dock is ideal for professionals requiring a high-performance, versatile workstation setup, enabling dual 4K 60Hz displays and high-speed data transfer.

Compatibility

This docking station requires a Thunderbolt 3 equipped computer with a Thunderbolt 3 port that supports USB Power Delivery 2.0. It is compatible with Windows 8, 8.1, 10, 11 and macOS 10.12 through 15.0 and 26.1. The downstream Thunderbolt 3 ports support connecting a second monitor, daisy-chaining other Thunderbolt devices, or connecting USB Type-C accessories.

Installation Notes

The dock includes a 1.8m host cable for flexible placement. It requires an AC adapter (included) for power, with an input voltage range of 100-240V AC and an output of 20V DC at 9A, providing up to 180W of power consumption. The operating temperature range is 0°C to 40°C (32°F to 104°F).

What's in the Box

  • 1x Thunderbolt 3 Docking Station
  • 1x Thunderbolt 3 Host Cable (1.8m)
  • 1x AC Adapter
  • 1x Power Cord
  • 1x Quick Start Guide
Specifications
Host Cable Length: 1.8m
Downstream TB3 Port Modes: 2nd monitor, daisy chain, USB Type-C accessories
Power Delivery: 85W
Warranty: 3 Years
Number of Displays Supported: 2
Bus Type: Thunderbolt 3
Industry Standards: Thunderbolt 3, USB Battery Charging Specification Rev. 1.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0
Maximum Data Transfer Rate: 40 Gbps (Thunderbolt 3), 10 Gbps (USB 3.1 Gen 2), 5 Gbps (USB 3.0), 2 Gbps (Ethernet)
Humidity: 0~95% RH
Color: Space Gray
Material: Aluminum
Product Length: 8.7 in [22.2 cm]
Product Width: 3.4 in [8.7 cm]
Product Height: 1.3 in [3.4 cm]
Weight of Product: 1.1 lb [0.5 kg]
Package Quantity: 1
Package Length: 11.7 in [29.8 cm]
Package Width: 5.8 in [14.8 cm]
Package Height: 3.7 in [9.5 cm]
Shipping Weight: 4.0 lb [1.8 kg]
Dual Display Resolution: 4096 x 2160p / 3840 x 2160p at 60Hz
Single 4K Display Resolution: 4096 x 2160p / 3840 x 2160p at 60Hz
Single 5K Display Resolution: 5120 x 2880p at 60Hz
Thunderbolt 3 Speed: 40 Gbit/s
Media Type: SD/MMC, SDHC, SDxC, microSD, microSDHC, microSDxC
Network Speed: 10/100/1000 Mbps
Thunderbolt 3 Ports: 2
DisplayPort: 1
USB 3.2 Type-C Ports: 1
USB 3.2 Type-A Fast-Charge Ports: 1
USB 3.2 Type-A Ports: 4
RJ-45 Ports: 1
Audio Ports: 1
OS Compatibility: Windows 8, 8.1, 10, 11; macOS 10.12 - 15.0, 26.1
System Requirements: Thunderbolt 3 equipped computer with Thunderbolt 3 port supporting USB Power Delivery 2.0
Power Source: AC Adapter
Power Delivery Output: 85W
Input Voltage: 100 - 240 AC
Input Current: 2.5 A
Output Voltage: 20V DC
Output Current: 9 A
Power Consumption: 180 Watts
Operating Temperature: 0C to 40C (32F to 104F)
Storage Temperature: -20C to 70C (-4F to 158F)
Brand: StarTech
MPN: TB3DOCK2DPPD
Type: Power Supply
Connectivity: USB
Power: 240V AC
