APC by Schneider Electric Catl LIB Rack with 9 X 80AH Battery Modules and 500A - LIBCAT2W9X80

APC by Schneider Electric LIBCAT2W9X80 Concise Descriptor

Overview

The APC by Schneider Electric LIBCAT2W9X80 is a 9U rackmount battery cabinet designed to extend the runtime of compatible uninterruptible power supply (UPS) systems. This unit houses nine 80Ah battery modules, providing significant additional power capacity for critical equipment during outages. It is engineered for data center and enterprise environments where continuous operation is paramount, specifically integrating with APC's Smart-UPS family.

Compatibility

This battery cabinet is designed for seamless integration with APC Smart-UPS models that support external battery cabinets. Specifically, it is compatible with the APC Smart-UPS 1000VA, 1500VA, 2200VA, and 3000VA units that feature the necessary external battery connector and management capabilities. Verify your specific Smart-UPS model's compatibility with external battery cabinets before purchase.

Installation Notes

Installation requires mounting the 9U cabinet into a standard 19-inch rack. The nine 80Ah battery modules must be installed within the cabinet. Connection to the host UPS unit is made via a dedicated external battery cable (typically sold with the UPS or separately). Ensure the UPS is powered off and disconnected from the mains before making any connections. Torque specifications for battery terminal connections must be adhered to, typically found in the host UPS or battery cabinet documentation. Operating temperature range for the batteries is critical for longevity and performance; consult the host UPS documentation for environmental requirements.

What's in the Box

• 1x APC by Schneider Electric LIBCAT2W9X80 Battery Cabinet
• 9x 80Ah Battery Modules
• 1x External Battery Connection Cable
• 1x Rack Mounting Hardware Kit
• 1x User Manual
