Panduit UTP28X1MVL Cat6A 28AWG 1-Meter Patch Cord

The Panduit TX6A-28™ UTP28X1MVL is a 1-meter Cat6A UTP patch cord engineered for high-density data center and network installations where cabinet space and airflow are critical. Built with 28AWG solid copper conductors, this violet patch cord measures just 0.185 inches (4.7mm) in diameter—significantly slimmer than standard 24AWG cables—enabling tighter bend radius, improved cable management, and better airflow in congested racks. Factory-terminated with high-performance modular plugs and pre-installed RapidID barcodes, it supports 10GBASE-T Ethernet, PoE/PoE+/PoE++ applications, and exceeds ANSI/TIA-568.2-D Category 6A performance standards for frequencies up to 500 MHz.

Key Features

• 28AWG solid copper construction — 0.185" (4.7mm) diameter for 30% space savings vs. 24AWG patch cords
• Pre-installed RapidID barcodes — enables port mapping and asset tracking via RapidID software without manual labeling
• Tangle-free latch design — prevents snags during installation and simplifies moves, adds, and changes in dense patch panel environments
• 100% factory performance tested — wire map, NEXT, and return loss verified on every cord
• CM/LSZH flame rating — low smoke zero halogen jacket suitable for plenum-adjacent or enclosed pathway installs
• Centered de-embedded plug with integral pair manager — maintains pair geometry through termination for consistent electrical performance
• Supports IEEE 802.3bt PoE++ Type 3/4 — delivers up to 90W in 24-cable bundles for high-power devices (IP cameras, wireless APs, LED lighting)

High-density installations demand cables that deliver 10GBASE-T performance without sacrificing rack space or airflow. The UTP28X1MVL addresses both: its 28AWG gauge reduces bundle diameter by roughly 30% compared to conventional 24AWG Cat6A patch cords, allowing integrators to fit more circuits per cable tray, maintain cooler cabinet temperatures, and meet TIA-942 data center pathway fill ratio guidelines without oversized conduit. The centered de-embedded plug design—paired with an integral pair manager inside the connector body—preserves twisted-pair geometry through the termination point, eliminating the alien crosstalk and return loss degradation common in field-terminated or poorly manufactured plugs. Every cord ships with a factory-applied RapidID barcode label on both ends, enabling one-scan port documentation via Panduit's RapidID mobile app or handheld scanner—eliminating handwritten labels, reducing human error during MAC operations, and providing a structured cabling audit trail from day one. The patented tangle-free latch incorporates a protective boot that prevents the RJ45 release tab from snagging on adjacent cables during insertion or removal, a persistent pain point in fully populated 48-port patch panels where finger access is limited.

Electrical performance exceeds ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA requirements across the full 1–500 MHz spectrum, with 100% factory testing of near-end crosstalk (NEXT) and return loss on every individual cord before packaging. This ensures reliable 10GBASE-T operation at full 100-meter channel distances when paired with compliant horizontal and backbone cabling. The U/UTP (unshielded twisted pair) construction simplifies grounding compared to shielded F/UTP or S/FTP alternatives—no drain wires, no bonding to patch panels—making it ideal for IT/AV integrators working in enterprise or education environments where screened cabling isn't mandated. The CM/LSZH jacket meets both UL 1863 (Communications) and low-smoke zero-halogen IEC standards, suitable for installations in enclosed cable trays, under raised floors, or in plenum-adjacent pathways where flame spread and smoke toxicity matter. Power-over-Ethernet support covers IEEE 802.3af (15.4W), 802.3at (30W), and 802.3bt Type 3/4 (60–90W) in bundles of 24 or 48 cables, tested per TIA-1096-A thermal loading requirements—critical for surveillance integrators running IP cameras, intercoms, and access control readers over a single Cat6A infrastructure.

The 1-meter length suits top-of-rack server-to-switch connections, patch panel-to-switch uplinks, and short cross-connects in telecommunications rooms where excess cable length creates management headaches. The violet jacket follows TIA-606-C color-coding conventions, commonly used to identify endpoint or equipment connections in structured cabling schemes. Packaged individually (10 cords per carton), each cord ships with both ends capped to prevent dust and debris contamination during storage or bulk installation. For integrators managing virtualized server environments, spine-leaf network topologies, or IP-based security systems where cabinet density and thermal management directly impact uptime, the TX6A-28 series delivers the same 10GBASE-T performance as standard Cat6A in a 30% smaller form factor—proven through cULus listing, TIA-568.2-D compliance, and Panduit's factory test data supplied with every batch.
