Hanwha MC06-001042A Silicon Cable Bushing Set for PNV-9080R

The Hanwha MC06-001042A is a small but mission-critical part: a silicon cable bushing set that maintains the IP-rated seal on the PNV-9080R outdoor camera. When the bushing is missing, swapped for a generic part, or damaged during a re-cable, the camera loses its weather seal and water enters the housing — often invisibly until the camera begins failing during the next rainy season.

Key Features

Genuine Hanwha bushing set for the PNV-9080R camera's cable entry

Silicon material rated for outdoor temperature swings and UV exposure

Preserves the camera's published IP66/IP67 rating when correctly installed

Sized for the standard data + power cable bundles published by Hanwha

Includes the multiple bushing sizes called out in the PNV-9080R install guide

Direct OEM replacement for damaged or missing factory bushings

Inexpensive insurance against premature camera failure caused by ingress

Cable bushings are a frequent cause of warranty disputes — the bushing is overlooked during a re-cable, the cable is replaced with a slightly different OD, or the bushing is reused once too often and loses its seal. The result is moisture in the camera, fogging on the inside of the dome, IR LED corrosion, and eventually image failure. Carrying spare OEM bushings on every service call is best practice.

Always install the bushing dry — do not use grease or silicon sealant, which can break down the bushing material over time. Tighten the gland nut to the value specified in the Hanwha install guide; over-tightening can pinch the cable and create a long-term cold-flow failure. Replace the desiccant pack inside the camera whenever the housing is opened, and re-torque the cover screws in the proper cross pattern.
