Middle Atlantic BGR Series Rack 38 Rack Units (66-1/2IN. ) 27IN. Deep Multibay with Rear - BGR-3827

Middle Atlantic BGR-3827 38U Floor-Standing AV/IT Rack with Rear Doors

Overview

The Middle Atlantic BGR-3827 is a 38-rack-unit, 27-inch-deep floor-standing rack designed for demanding AV, IT, and physical security infrastructure deployments. Built from steel with a black wrinkle powder coat finish, the BGR-3827 hits a practical balance between usable depth (24.4 in) and footprint (23 in wide) — deep enough to house full-depth servers, NVRs, patch panels, and power distribution units without the bulk of a 30-inch cabinet. It ships as a frame-only configuration, giving integrators flexibility to add doors, side panels, and accessories from Middle Atlantic's full catalog based on actual project requirements.

The 38 RU height (66.63 in usable) accommodates large system builds — a typical enterprise security head-end with a 16-channel NVR, UPS, managed PoE switch stack, patch panel, and cable management will consume 18–25 RU, leaving meaningful headroom for growth. At 70.63 in overall height, the rack fits standard commercial ceilings and passes through standard doorways without overhead clearance issues in most facilities.

Key Features

• 3,000 lb UL-Listed Load Capacity: The BGR-3827 carries up to 3,000 lbs of equipment — UL Listed at that rating, not just a marketing claim. That means a fully loaded build with dense 2U servers, multiple UPS units, and a full NVR stack won't push this frame anywhere near its limit. Overkill for a camera head-end; exactly right for a converged IT/security/AV rack in a data room.
• Seismic Rating — 1,175 lb Capacity, OSHPD OPM-0444-13: The frame carries an OSHPD certification (OPM-0444-13) under HCAI (formerly OSHPD) seismic requirements — a hard requirement for healthcare facilities in California and other jurisdictions with seismic codes. If your project spec calls out ASCE seismic compliance, this rack meets it. Seismic-rated load capacity is 1,175 lbs, so equipment selection matters on seismic-designated installs.
• TAA Compliant, USA-Made: Federal Ops country of origin is USA, and the rack is TAA compliant — required for federal contracts, GSA schedules, and most state/local government procurement. If your bid documents call out TAA, this checks that box without substitution risk. Pair with TAA-compliant NVRs for a fully compliant head-end build.
• Gangable Design: The BGR-3827 is gangable — multiple units bolt together side-by-side into a unified multi-bay array. For large security operations centers or NOCs where adjacent racks need to share cable runs and maintain a clean, rigid structure, this eliminates the gap and flex you get from free-standing units placed next to each other.
• Forward Rackrail with Forward Compatibility: The forward rackrail design positions equipment at the front of the frame, making it straightforward to install and service front-access equipment. The forward-compatible designation means accessories and components designed for the BGR platform install without modification — useful when expanding or upgrading an existing Middle Atlantic rack system over a multi-year project lifecycle.
• 25mm x 150mm Swing Handles: The integrated swing handles make repositioning a loaded or partially loaded rack manageable for a two-person team without needing a pallet jack for short moves during installation. Handles fold flat when not in use, keeping the footprint clean.
• Rear Door Included: Unlike frame-only open racks, the BGR-3827 ships with a rear door — cable management, airflow control, and physical security for rear-access cabling are addressed out of the box. Front door and side panels are separate accessories if a fully enclosed cabinet configuration is needed. See rack enclosures and cabinets for closed-cabinet alternatives if the project requires full enclosure.
• Steel Construction, Black Wrinkle Powder Coat: The wrinkle powder coat is more durable against scratches and handling damage than standard smooth powder coat — relevant in installation environments where the rack gets moved repeatedly before final positioning. Steel construction at 131 lbs shipping weight means this is a solid, permanent installation frame, not a light-duty unit.

Integration and Compatibility

The BGR-3827 accepts standard 19-inch rackmount equipment across all 38 RU. The 24.4-inch usable depth accommodates most commercial-grade NVRs, managed PoE switches, 1U/2U servers, and UPS units without rear-rail extensions. Deep-chassis equipment (full-depth 1U servers at 28–29 inches) may require the full 27-inch cabinet depth — verify chassis depth against the 24.4-inch usable figure, not the 27-inch cabinet depth. The gangable design is compatible with other BGR-series frames for multi-bay expansion. UPC is included for procurement and inventory tracking.

Frequently Asked Questions

Q: Is the BGR-3827 TAA compliant?

A: Yes. The BGR-3827 is TAA compliant with a Federal Ops country of origin of USA — suitable for federal, state, and local government procurement contracts requiring TAA compliance.

Q: What is the seismic certification on the BGR-3827?

A: The BGR-3827 holds OSHPD certification OPM-0444-13 under HCAI (formerly OSHPD) seismic requirements, meeting ASCE seismic standards. Seismic-rated load capacity is 1,175 lbs. This makes it compliant for healthcare facility installations in California and other jurisdictions with seismic code requirements.

Q: Does the BGR-3827 ship with a front door?

A: No. The BGR-3827 is a frame-only configuration that includes a rear door. Front door and side panels are sold separately as Middle Atlantic accessories.

Q: Can multiple BGR-3827 units be installed side by side?

A: Yes. The BGR-3827 is gangable, meaning multiple units can be bolted together into a multi-bay array for large head-end or NOC installations.

Q: What is the usable depth and rack unit count of the BGR-3827?

A: The BGR-3827 provides 24.4 inches of usable depth (27-inch overall cabinet depth) and 38 rack units of usable height (66.63 inches usable, 70.63 inches overall).

Q: What is the UL-listed load capacity of the BGR-3827?

A: The BGR-3827 carries a UL-listed load capacity of 3,000 lbs. Note that the seismic-rated load capacity is separately specified at 1,175 lbs for seismic-designated installations.

Jerry Tildsen

The BGR-3827 (often searched as BGR 3827) is one of the few floor-standing racks I recommend without hesitation for healthcare and government security head-ends specifically because of that OSHPD OPM-0444-13 certification — it's not a self-declared seismic rating, it's a third-party verified certification under California's HCAI program, which is the toughest seismic compliance bar in the country. That distinction matters on bid submittals.

Technical Highlights:

• 3,000 lb UL Load Rating: Verified at 3,000 lbs by UL, not just listed — this frame handles dense mixed-use builds (NVR + UPS + server stack) without any structural concern whatsoever.
• 24.4 in Usable Depth: The 27-inch cabinet gives you 24.4 inches of actual usable depth — enough for virtually all commercial NVRs and 1U switches, but you need to verify full-depth server chassis individually since a 28-inch server chassis won't fit without rear rail extensions.
• Gangable Multi-Bay: For SOC or NOC builds requiring 3–6 adjacent racks, the gangable design eliminates inter-rack gaps and creates a rigid unified bay — cleaner cable management, better airflow, and a more professional finished installation than free-standing units.

Deployment Considerations:

• This is a frame-only product — budget for front door, side panels, and any cable management accessories separately. Don't spec the rack without accounting for the enclosure accessories if the project requires a fully closed cabinet.
• Seismic load capacity is 1,175 lbs — well under the static 3,000 lb UL figure. On seismic-designated installs, equipment selection needs to stay within that 1,175 lb ceiling, not the static rating.

For a California hospital security upgrade or a federal facility head-end where the RFP specifies OSHPD seismic compliance and TAA, the BGR-3827 is the correct frame — it satisfies both requirements out of the box without special ordering a modified configuration.
