Axis 01169-001 DIN Rail 24V DC 100W Power Supply
Overview
The Axis 01169-001 is a 100W regulated 24V DC power supply built for DIN rail mounting in surveillance cabinet distribution systems. It solves the core problem in multi-camera deployments: centralized, stable power delivery to dozens of devices without the cable clutter and voltage sag of individual power supplies. The 01169-001 fits the standard 53×91×58 mm DIN rail footprint — it slides into any cabinet infrastructure already designed around industrial power distribution standards.
Compatibility
This supply is designed for Axis distributed power systems, particularly in conjunction with the AXIS T98A-VE Cabinet Series. It outputs 24V DC at up to 4.2A — enough current to feed multiple Axis IP cameras, network video recorders, or mixed surveillance hardware in a single cabinet. Verify your specific camera or NVR datasheet for 24V power input requirements; not all Axis devices accept 24V (many require 12V or PoE). The regulated output ensures stable voltage delivery across cable runs typical in cabinet-to-wall or cabinet-to-remote-device wiring scenarios, reducing brownout risk to sensitive network electronics.
Installation Notes
Operating temperature range is −40°C to 70°C (−40°F to 158°F), suitable for unheated or climate-controlled equipment rooms. Input accepts standard facility power: 100–240V AC at 31W draw. Mounting is straightforward — standard DIN rail clips (no tools beyond a screwdriver for terminal blocks). Compact footprint (196g / 0.43 lb) preserves cabinet real estate. Wire termination uses standard industrial screw blocks; use 14 AWG or larger for the 24V DC output leads to avoid voltage drop on longer runs.
