APC Smart-ups SRT 192V 8 AND 10KVA RM Battery Pack - SRT192RMBP2 - Battery Pack

APC by Schneider Electric SRT192RMBP2 Rack-Mount Extended Runtime Battery Pack

Overview

The APC by Schneider Electric SRT192RMBP2 is a 192V, 1920VAh sealed lead acid (VRLA) rack-mount battery pack designed to extend runtime on Smart-UPS SRT 8KVA and 10KVA systems. Occupying 3U of rack space in a 432mm-wide form factor, this unit slots directly into existing rack infrastructure alongside the host UPS — no external cabinets, no custom shelving required. If your critical load needs more than the base UPS runtime can deliver, the SRT192RMBP2 is the purpose-built answer for that system family.

For security operations centers, hospital data closets, and network infrastructure rooms where the SRT 8/10KVA is already deployed, this battery pack extends your window of protected runtime without requiring a UPS replacement or a parallel UPS architecture.

Key Features

• 192V / 1920VAh VRLA Battery String: The sealed lead acid (VRLA) chemistry means zero maintenance — no watering, no venting requirements beyond standard OSHA guidelines. At 1920VAh, this pack delivers meaningful additional runtime behind an 8KVA or 10KVA load, particularly at partial load, where SRT-series UPS efficiency is highest. Sealed construction also reduces battery room regulatory burden for OSHPD-regulated healthcare facilities.
• OSHPD Certification: The SRT192RMBP2 carries OSHPD (Office of Statewide Health Planning and Development) certification — a hard requirement for electrical equipment installed in California healthcare facilities. If your deployment is in a CA hospital, clinic, or licensed healthcare building, this certification eliminates a procurement blocker that non-certified alternatives create.
• RoHS Compliance: RoHS compliance is increasingly a procurement requirement for enterprise and public-sector buyers. Verified here — no restricted hazardous substances, which matters for both disposal compliance and government purchasing programs.
• REACH Compliance: Meets EU REACH chemical substance regulations. Relevant for multi-site enterprises with European operations or EU-export requirements.
• Rack-Mount Form Factor (3U / 432mm W × 130mm H × 682mm D): At 130mm tall (3U), the SRT192RMBP2 fits standard 19-inch racks without consuming disproportionate rack space. The 682mm depth means you need adequate rack depth — verify your cabinet is at least 700mm deep before ordering. Width is 432mm, standard for rack-mount UPS accessories.
• 5-Year Battery Life Rating: APC rates the battery cells at 5 years of service life under normal conditions. For budgeting purposes, build replacement at year 4–5 into your preventive maintenance schedule — VRLA performance degrades gradually, and a battery approaching end-of-life under a critical load is an avoidable risk.
• Operating Temperature 0–40°C: Standard IT equipment range. If your MER or data closet runs hot (above 35°C ambient consistently), expect accelerated battery aging — VRLA cells are temperature-sensitive and every 10°C above 25°C roughly halves battery life. Keep the room at or below 25°C for full service life.
• Storage Temperature –15 to 45°C: Wide storage range means the unit can be warehoused in unconditioned space before deployment without damage, useful for large deployments with staged rollouts.
• Black Finish: Matches standard rack aesthetics in data centers and wiring closets — a minor but relevant point for facilities with standardized rack appearance policies.

Integration & Compatibility

The SRT192RMBP2 is engineered specifically for the APC Smart-UPS SRT 8KVA and 10KVA rack-mount systems. It connects via the proprietary SRT battery bus — do not attempt to use this pack with SRT 5KVA or SRT 6KVA units, as bus voltage and connector configurations differ. Multiple rack UPS battery packs can be chained to further extend runtime, subject to the host UPS's maximum extended runtime pack limit (verify in the host UPS installation guide).

For planning your runtime requirements, consult an online UPS runtime calculator or your UPS documentation — actual runtime depends on load percentage, temperature, and battery age. This pack is not compatible with Smart-UPS SMX, SMT, or SUA series.

If you are designing a rack build around this pack, pair it with appropriate rack PDUs and confirm your cabinet depth before finalizing the order — the 682mm depth of this unit is the binding constraint for most shallow-depth racks.

Frequently Asked Questions

Q: Which UPS models is the SRT192RMBP2 compatible with?

A: The SRT192RMBP2 is designed for use with APC Smart-UPS SRT 8KVA and 10KVA rack-mount systems. It is not compatible with Smart-UPS SMX, SMT, SUA series, or SRT models outside the 8KVA/10KVA range.

Q: How many SRT192RMBP2 packs can I connect to a single SRT UPS?

A: The maximum number of extended battery packs per SRT 8KVA/10KVA host is documented in the host UPS installation guide. Exceeding that limit can damage the UPS or create unsafe charging conditions — always verify before chaining multiple packs.

Q: What battery technology does the SRT192RMBP2 use?

A: Sealed Lead Acid (VRLA — Valve-Regulated Lead Acid). Maintenance-free and spill-proof under normal operating conditions. No watering, no venting required beyond standard guidelines.

Q: Is the SRT192RMBP2 OSHPD certified?

A: Yes. The SRT192RMBP2 holds OSHPD certification, making it compliant for installation in California healthcare facilities where OSHPD approval is required for electrical equipment.

Q: What is the rated battery life of the SRT192RMBP2?

A: APC rates the battery cells at 5 years. Actual service life depends on operating temperature, discharge frequency, and depth of discharge. Consistent operation above 25°C ambient will reduce effective life — keep the host environment cooled for best results.

Q: What are the physical dimensions of the SRT192RMBP2?

A: 432mm wide × 130mm tall × 682mm deep (approximately 17.0
