APC Smart-ups RT 19IN Rail KIT for Smart-ups RT 3/5/7.5/10KVA - SURTRK2

APC by Schneider Electric SURTRK2 Rail Kit

Overview

The APC Smart-UPS RT 19in Rail Kit, model SURTRK2, provides a secure and organized mounting solution for APC Smart-UPS RT 3, 5, 7.5, and 10kVA units within a standard 19-inch server rack. This kit is essential for deploying UPS systems in data centers or network closets where space is optimized and equipment must be reliably secured. Its design facilitates proper airflow and accessibility for maintenance, ensuring the UPS operates efficiently and can be serviced without disruption.

Compatibility

This rail kit is specifically designed for APC Smart-UPS RT models with capacities of 3kVA, 5kVA, 7.5kVA, and 10kVA. It is compatible with units intended for 19-inch rack mounting. Ensure your specific Smart-UPS RT model is listed or designed for this form factor before ordering.

Installation Notes

The SURTRK2 kit includes adjustable rails that extend to accommodate various depths within a 19-inch rack. Installation requires basic tools, typically a Phillips head screwdriver and potentially a T20 Torx driver for securing the UPS to the rails. The rails attach to the server rack's vertical mounting posts, and the UPS unit then slides onto these rails and is secured. Refer to the user manual for detailed step-by-step instructions and torque specifications to prevent damage to the rack or UPS.

What's in the Box

• 2x Adjustable Rack Mounting Rails
• 4x Rack Mounting Screws
• 4x Cage Nuts
• 4x T20 Torx Screws
• 1x User Manual
