APC Rack PDU Metered 1U 22.1KW 32A 400V or 17.3KW 415V 30A (3) C13& (6) C19 - APDU9886-1UX960

APC by Schneider Electric APDU9886-1UX960 Concise Descriptor

Overview

The APC APDU9886-1UX960 is a 1U metered rack Power Distribution Unit (PDU) designed for high-density IT environments. It provides granular power monitoring at the PDU level, enabling you to track load consumption and identify potential overloads before they impact critical equipment. This unit is suitable for data centers and server rooms requiring precise power management for rack-mounted servers, network switches, and storage arrays. The APDU9886-1UX960 supports input voltages of 400V or 415V, delivering up to 22.1kW or 17.3kW respectively, with a 32A or 30A input current draw.

Compatibility

This PDU is designed for integration into standard 19-inch server racks. Its output configuration includes three C13 outlets and six C19 outlets, accommodating a variety of equipment power cords. It is compatible with APC's EcoStruxure IT management platform for remote monitoring and control, as well as third-party DCIM solutions that support SNMP or Modbus TCP protocols for power data aggregation. Ensure your rack infrastructure can support the PDU's physical dimensions and weight, and that your facility's electrical panel can handle the specified input voltage and current ratings.

Installation Notes

The APDU9886-1UX960 requires a 32A or 30A, 400V or 415V, 3-phase power source connection via its IEC 60309 input connector. Proper grounding is essential for safe operation. The unit mounts horizontally in a standard 19-inch rack, occupying 1U of vertical space. Torque specifications for the input power connection should be followed per local electrical codes and the PDU's installation guide to ensure a secure connection and prevent overheating. Ensure adequate airflow around the PDU and connected equipment within the rack to maintain optimal operating temperatures.

What's in the Box

• 1x APC APDU9886-1UX960 Metered Rack PDU
• 1x IEC 60309 Input Power Cord
• 1x Mounting Hardware Kit (Rack Mount Brackets)
• 1x Serial Configuration Cable
• 1x Quick Start Guide
