APC by Schneider Electric PD1P20ABBSD Single-Pole Breaker

Overview

The APC by Schneider Electric PD1P20ABBSD is a single-pole, 20-amp bolt-on circuit breaker designed for specific Square D electrical panel configurations. It serves as a replacement or upgrade component, providing essential overcurrent protection for critical equipment within a power distribution system. This breaker is intended for applications where reliable power is paramount, such as protecting sensitive IT infrastructure or industrial automation components.

Compatibility

This PD1P20ABBSD breaker is engineered for direct installation into Square D QO and Homeline load centers and breaker boxes. Its bolt-on style ensures secure mounting within compatible panelboards. Verify your panel's compatibility before purchase to ensure correct fit and function. This is not compatible with standard plug-in style breakers or panels from other manufacturers.

Installation Notes

Installation requires a qualified electrician. The PD1P20ABBSD features a standard lug for connection to the busbar and a bolt-on mechanism for secure attachment. Ensure the main breaker to the panel is de-energized before attempting installation. Torque specifications for the busbar connection should adhere to Square D panel guidelines to prevent overheating or loose connections. The breaker is rated for 120/240VAC circuits.
