Altronix T3SK75F16D 16-Door Access Control Kit

Altronix T3SK75F16D 16-Door Access Control Integration Kit

Overview

The Altronix T3SK75F16D is a comprehensive 16-door access control and power integration solution designed for installers and integrators deploying Software House access systems. This complete kit bundles the Trove3SH3 control platform with intelligent reader modules, card readers, distributed power management, and battery backup components—eliminating guesswork in system architecture and reducing BOM complexity for mid-scale deployments.

The T3SK75F16D combines centralized access logic with distributed field power and door control, enabling secure credential verification across 16 access points with integrated power supervision and battery-backed operation. This kit supports standard credential readers and delivers the core infrastructure required for reliable multi-door installations without requiring separate procurement of compatible components.

Key Features

• 16-Door Capacity: Native support for 16 independent access points with individual door control and status reporting
• Trove3SH3 Control Platform: Included Software House access control processor providing credential evaluation, door lock control logic, and integrated reporting
• Dual eFlow Reader Modules: Kit includes one eFlow104NB (4-reader input module) and one eFlow102NB (2-reader input module) for flexible credential reader connectivity and expandable reader configurations
• ACM8CB Card Reader Modules: Two Access Control Modules deliver weighted output distribution across door circuits with integrated supervision and tamper reporting
• PD8ULCB Power Distribution: UL-Listed power distribution and battery charging module providing regulated output to reader modules and auxiliary circuits
• RSB2 Battery Backup: Integrated rechargeable battery supervision and backup power delivery enabling secure lockdown operation during AC power loss
• Integrated Power Supervision: Real-time monitoring of distributed power delivery to detect faults, brownout conditions, and supply anomalies
• Field-Installable Architecture: Modular component layout supports wall, DIN-rail, or cabinet mounting with clear terminal assignments for rapid deployment

Integration & Compatibility

The T3SK75F16D is purpose-built for Software House-compatible access control deployments. All kit components are pre-qualified for integration with the Trove3SH3 control engine, eliminating cross-vendor compatibility risk. The dual eFlow reader modules support both standard Wiegand and Software House serial protocols, enabling integration of legacy badge readers or third-party credential interfaces. The ACM8CB modules provide weighted solenoid control suitable for electric strikes, magnetic locks, and monitored door position sensors.

Power distribution through the PD8ULCB ensures regulated supply to all reader circuits, reducing voltage-drop failures in extended reader cable runs. The RSB2 battery module maintains backup power to critical circuits, including reader power and door lock control, enabling forced-egress operation and auditability during extended power loss.

Package Contents

• Trove3SH3 Access Control Processor
• eFlow104NB (4-Door Reader Input Module)
• eFlow102NB (2-Door Reader Input Module)
• ACM8CB Card Reader Module (×2)
• PD8ULCB Power Distribution and Charging Module
• RSB2 Battery Backup Module

Jerry Tildsen

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

I've evaluated the Altronix T3SK75F16D during pre-deployment planning for a 16-door pharmaceutical facility upgrade, and this kit eliminates several common integration headaches. Having the Trove3SH3, reader modules, power distribution, and battery backup bundled together removes the risk of incompatible component selection and accelerates system validation.

Technical Highlights:

• Reader Flexibility: The combination of eFlow104NB and eFlow102NB modules delivers 6 total reader inputs, supporting badge readers, keypads, or biometric interfaces across the 16-door layout
• Power Supervision Integrity: The PD8ULCB distributed power module ensures regulated delivery to reader circuits, critical for stable credential recognition in high-EMI manufacturing environments
• Battery-Backed Egress: The RSB2 module maintains power to door locks and reader circuits during AC loss, enabling secure lockdown without loss of auditability

Deployment Considerations:

• Plan reader placement early—the eFlow module assignments (4-door and 2-door configurations) should align with physical door groupings to minimize cable runs and simplify troubleshooting
• Verify battery capacity requirements during design phase; the RSB2 module should be sized to maintain reader power for the expected outage duration at your site
• Use the ACM8CB module assignments to distribute solenoid load evenly; verify final strike amperage ratings against module output specs during commissioning

For integrators standardizing on Software House architecture, the T3SK75F16D represents a well-thought-out kit that reduces procurement cycles and field validation time. I recommend this kit for facilities requiring reliable 16-door access with battery-backed operation and integrated power supervision.
