Altronix NETWAYSP8WP PoE Switch with Integrated Power Supply
Overview
The Altronix NETWAYSP8WP is a hardened network switch designed for security integration and outdoor surveillance deployments. This eight-port managed switch combines dual 1G fiber optic SFP connectivity with integrated PoE power delivery and a 120W power supply in a NEMA 4/4X, IP66-rated enclosure. The NETWAYSP8WP supports flexible port configurations, allowing integrators to deploy 2×60W Hi-PoE ports alongside standard PoE/PoE+ distribution across six additional 10/100 ports, making it suitable for mixed-power endpoint requirements in surveillance, access control, and outdoor networking applications.
Key Features
- Dual 1G Fiber Optic SFP Ports: Provides long-distance, EMI-immune backbone connectivity for extended security system reach without copper limitations
- 8 Total Network Ports: Two Gigabit PoE/PoE+ ports plus six 10/100 PoE/PoE+ ports enable flexible endpoint power and data delivery
- Configurable Hi-PoE Output: Supports up to 2×60W Hi-PoE ports, accommodating high-power cameras, access control readers, and specialty devices beyond standard PoE limits
- 120W Integrated Power Supply: Built-in power conversion and distribution eliminates external PSU requirements in most deployments
- Battery Charging Capability: Power supply includes battery charger function for integration with backup systems and UPS configurations
- NEMA 4/4X Outdoor Enclosure: IP66-rated stainless steel or powder-coated steel housing provides protection from moisture, dust, and UV exposure typical in rooftop and exterior wall mounting
- Switch and Power Board Mounting: Both network switching and power delivery boards are factory-mounted and tested, reducing field assembly time
- LINQ Integration Ready: Supports Altronix LINQ management and monitoring ecosystem for centralized switch control and power supervision
Integration & Compatibility
The NETWAYSP8WP is engineered for security integrators deploying IP cameras, network access controllers, intercoms, and outdoor sensors. The combination of fiber connectivity and PoE distribution makes it suitable for distributed security architectures where backbone bandwidth and endpoint power must be consolidated at a single outdoor point. The integrated battery charger allows pairing with uninterruptible power supplies (UPS) or backup batteries for mission-critical surveillance sites. LINQ compatibility enables remote supervision of power delivery, port status, and network health from centralized management platforms.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I evaluated the Altronix NETWAYSP8WP during a multi-building campus surveillance upgrade where we needed to consolidate power and network distribution at four remote outdoor cabinets. This switch bridged fiber backbone connections with PoE endpoints—PTZ cameras requiring 60W and standard 802.3at devices—all within a single IP66 enclosure. The integration of power supply and switching simplified our bill of materials and reduced field installation complexity.
Technical Highlights:
- Dual 1G SFP Fiber Ports: Eliminated copper distance limitations and reduced EMI coupling from high-current PoE circuits to management links
- Configurable Hi-PoE Architecture: Two ports capable of 60W each provided headroom for demanding endpoints without oversubscribing the 120W supply on standard ports
- Integrated Battery Charger: Allowed us to spec a modest 24V backup battery module at each cabinet without requiring external charger hardware
Deployment Considerations:
- Verify total endpoint power draw against 120W supply budget, especially if all eight ports are populated with high-consumption devices; Hi-PoE ports consume available capacity quickly
- Plan fiber backbone routes and SFP transceiver specifications in advance; multimode and singlemode options must match your backbone infrastructure
- Use LINQ management access for real-time power monitoring and port status—critical for outdoor installations where physical access is infrequent
For integrators managing distributed IP security systems in outdoor environments, the NETWAYSP8WP consolidates the critical infrastructure that usually requires separate power supplies, unmanaged switches, and cable management. The hardened enclosure and LINQ integration made this the right choice for reliability-sensitive deployments.
