Altronix AL600ADA 24VDC Power Supply Board

Altronix AL600ADA Power Supply Board

Overview

The Altronix AL600ADA is a 24VDC power supply board designed to provide reliable power for surveillance and access control systems. It features AC fail supervision and battery backup capabilities, ensuring continuous operation during power outages. This board is ideal for integration into custom enclosures or existing rack-mount systems where a compact, high-current power solution is required. The AL600ADA model specifically delivers 24VDC output at a maximum of 12A, supporting up to 12 fused or PTC protected outputs, making it suitable for powering multiple devices like cameras, access control readers, or network equipment.

Compatibility

This power supply board is designed to work with the VR6 Voltage Regulator and is often bundled with the ACMS8CB Dual Input Access Power Controller, as seen in kits like the ACMS8CBK1. It is intended for integration into systems requiring a robust 24VDC power source, commonly found in commercial security and automation deployments. While not a standalone unit, it serves as a core component for building custom power distribution solutions.

Installation Notes

The AL600ADA is a board-level component requiring integration into a suitable enclosure. It accepts 115VAC input and provides a regulated 24VDC output. The board supports battery backup, necessitating the installation of appropriate standby batteries. Its form factor is suitable for rack-mount installations, and it can also be wall or pole-mounted when housed in a compatible enclosure. Proper wiring and grounding are essential for safe and reliable operation.

What's in the Box

• 1x VR6 Voltage Regulator
• 1x ACMS8CB Dual input Access Power Controller
