Panduit LAMA6-14-C Mechanical Lug

Overview

The Panduit LAMA6-14-C is a single-hole mechanical lug designed for terminating conductors in electrical systems. It provides a reliable connection point for wiring, ensuring electrical continuity and safety in industrial and commercial installations. This lug is specifically engineered for applications requiring a secure, permanent connection, such as power distribution or equipment grounding where vibration or thermal cycling could compromise less robust methods. The LAMA6-14-C is built for use with 6 AWG wire and a 1/4 inch stud size, offering a precise fit for specific conductor gauges and mounting hardware.

Compatibility

This lug is designed for use with 6 AWG stranded or solid copper conductors. It is intended for termination onto a 1/4 inch (M6) threaded stud or bolt. While not specific to any single surveillance product line, it serves as a critical component in the power infrastructure supporting various security devices, including IP cameras, network switches, and access control panels that require direct electrical connections.

Installation Notes

For optimal performance and safety, the LAMA6-14-C lug requires proper installation. The conductor must be fully inserted into the barrel, and the lug must be torqued to Panduit's recommended specification of 30 in-lbs (3.4 Nm) using a calibrated torque tool. Ensure the conductor is clean and free of debris before insertion. The lug is designed for use in dry, indoor environments.
