Middle Atlantic P8105-4DP Double-Gang Power Plate for 4 Duplex Devices

Overview

The P8105-4DP is a double-gang (2-gang) AC Series power plate designed to populate raised floor box installations with up to four duplex receptacle positions. If you're finishing out an Middle Atlantic floor box and need a clean, code-compliant face plate that accommodates a high device count, this is the plate to specify. It ships with four duplex knockouts — meaning you can wire it for the exact receptacle count the deployment calls for rather than being locked into a prefilled layout. UL Listed, so it meets the compliance bar for commercial and institutional installations without additional verification steps.

Compatibility

The P8105-4DP is engineered specifically for the AC8105 and AC8850 Raised Floor Box series from Middle Atlantic. It is also compatible with the Walkerflex Modular Wiring System, which lets it integrate into structured in-floor wiring runs common in open-plan commercial environments, training rooms, and broadcast/AV floors. Do not attempt to fit this plate in standard wall-box or rack-panel cutouts — the mounting geometry is specific to the AC Series raised floor box form factor. If your project uses a different Middle Atlantic power distribution enclosure outside the AC8105/AC8850 family, verify dimensional compatibility before ordering.

Installation Notes

The double-gang form factor provides the surface area needed to seat four duplex devices side by side within a single floor box opening. Knockouts are pre-scored for clean removal — use standard knockout tools rather than improvised methods to avoid deforming the plate face. Wire each duplex position to the Walkerflex system or hardwired branch circuits per local electrical code. UL Listing applies to the plate itself; the completed assembly must still meet NEC requirements for the specific installation class.
