Frame Rate:
30fps
IP Video Input:
64-ch, 12MP
Incoming Bandwidth:
320 Mbps
Outgoing Bandwidth:
256 Mbps
Incoming Bandwidth (RAID Mode:
200 Mbps
Outgoing Bandwidth (RAID Mode:
200 Mbps
HDMI 1 Output:
4K/60Hz, 1080p/60Hz
HDMI 2 Output:
1920×1080/60Hz, 1280×1024/60Hz
VGA 1 Output:
1920×1080@60Hz
VGA 2 Output:
1920×1080@60Hz, 1280×1024@60Hz
Video Output Mode:
HDMI 1/VGA 1 (main), HDMI 2/VGA 2 (aux)
CVBS Output:
1-ch BNC, 75Ω, PAL/NTSC
Audio Output:
2-ch, RCA (Linear, 1 KΩ)
Two-Way Audio:
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding Format:
H.265+/H.265/H.264+/H.264/MPEG4
Recording Resolution:
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/720p/
Synchronous Playback:
16-ch
Decoding Capability:
1-ch@32 MP (30 fps)/2-ch@12 MP (20fps)/4-ch@8 MP (25fps)/8-ch@4 MP (30fps)/16-ch@1080p (30fps)
Dual-Stream Recording:
Support
Stream Type:
Video, Video & Audio
Audio Compression:
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM
Remote Connection:
128
Network Protocol:
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface:
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
RAID Type:
RAID 0/1/5/6/10
Serial Interface:
1 RS-485 (full-duplex), 1 RS-232, 1 keyboard
SATA:
8 SATA interfaces supporting hot-plug
ESATA:
1 eSATA interface
Capacity:
Up to 10TB capacity for each disk
Alarm In/Out:
16/4
USB Interface:
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Power Type:
100 to 240 VAC, 50 to 60 Hz
Consumption:
≤ 30 W
Working Temperature:
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity:
10% to 90%
Chassis:
3U chassis
Dimension (W × D × H:
445 × 465 × 92 mm ( 17.5"× 18.3" × 3.6")
Weight:
≤ 10 kg (22 lb)
FCC:
Part 15 Subpart B, ANSI C63.4-2014
CE:
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Housing Color:
White
