Frame Rate:
30fps
Field of View:
56.1° to 2.0° (H), 33.4° to 1.1° (V)
Zoom Speed:
Approx. 7.8 s (optical lens, wide-tele)
Working Distance:
10 mm to 1500 mm (wide-tele)
Aperture Range:
F1.5 to F4.5
Focal Length:
7.5 mm to 270 mm, 36× optical zoom
Image Enhancement:
HLC/BLC/3D DNR/Optical Defog/EIS
Sub-Stream:
25fps 704×576, 30fps 704×480
Max. Resolution:
4096 × 2160
Main Stream:
30fps @ 4096×2160
Third Stream:
30fps 1920×1080
Network Storage:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/CIFS), ANR
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
API:
ONVIF, ISAPI, CGI, HIKVISION SDK
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users., 3 levels: Administrator, Operator and User
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Security Measures:
User auth, MAC auth, HTTPS, 802.1x, IP filtering
Alarm Linkage:
Preset, Patrol Scan, Pattern Scan, Recording, FTP/Email
BNC:
1.0 V [p-p]/75 Ω, NTSC (or PAL) composite, BNC
Alarm Output:
2-ch alarm output
Alarm Input:
7-ch alarm input
Audio Input:
1-ch audio input, 2 to 2.4 V[p-p], 1 KΩ ± 10%
Audio Output:
1-ch audio output, line level, impedance: 600 Ω
Network Interface:
1 RJ45 10 M/100 M Ethernet Interface, Hi-PoE
RS-485:
Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
H.264:
Yes
H.265:
Yes
H.264 Type:
Baseline Profile/Main Profile/High Profile
Video Compression:
H.265+/H.265/H.264+/H.264, H.265/H.264/MJPEG, H.265/H.264/
H.265 Type:
Main Profile
Video Bitrate:
32 Kbps to 16384 Kbps
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bitrate:
64Kbps G.711, 16Kbps G.722.1, 16Kbps G.726, 32-160Kbps
SVC:
Support
Sensor Type:
2/3" progressive scan CMOS
Min. Illumination:
0.0005 Lux (B/W), 0.005 Lux (Color)
White Balance:
Auto/Manual/ATW/Indoor/Outdoor
Gain:
Auto/Manual
Shutter Time:
1/1 s to 1/30,000 s
Day & Night:
IR Cut Filter
Digital Zoom:
16×
Privacy Mask:
24 programmable polygon privacy masks
Focus Mode:
Auto/Semi-automatic/Manual
Features:
Digital WDR
Rapid Focus:
Yes
Movement Range (Pan:
360° endless
Pan Speed:
Configurable, from 0.1°/s to 350°/s, preset speed: 540°/s
Movement Range (Tilt:
From -20° to 90° (auto flip)
Tilt Speed:
Configurable, from 0.1°/s to 240°/s, Preset Speed: 400°/s
Proportional Zoom:
Yes
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Yes
Park Action:
Preset/Pattern/Patrol/Auto/Tilt/Random/Frame/Panorama
3D Positioning:
Yes
PTZ Status Display:
Yes
Preset Freezing:
Yes
Scheduled Task:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output
Smart Tracking:
Auto tracking (human, vehicle)
Smart Record:
ANR (Automatic Network Replenishment), Dual-VCA
ROI:
Eight fixed region for each stream
Perimeter Protection:
Intrusion, Line Crossing, Region Entrance, Region Exiting,Support alarm triggering by specified target types (human and vehicle),Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
Event Detection:
Unattended Baggage, Object Removal, Face, Audio Detection
Material:
Aluminum alloy
Dimensions:
Φ 231.1 mm × 355.6 mm (Φ 9.10" × 14")
Weight:
Approx. 6 kg (13.23 lb)
Protection Level:
IP67, IK10, 6kV surge protection
Power Type:
24 VAC/Hi-PoE (60W/50W max)
Working Temperature:
Temperature: -40°C to 70°C (-40°F to 158°F)
Working Humidity:
Humidity: ≤ 90%
Housing Color:
White
