FOV:
48.8° to 2.3° (Wide-Tele)
Zoom Speed:
Approx. 4.8 s (Optical Lens, Wide-Tele)
Working Distance:
10 mm to 1500 mm (Wide-Tele)
Aperture Range:
F1.5 to F3.4
Focal Length:
5.9 mm to 177 mm, 30× Optical Zoom
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Max. Resolution:
2560 × 1440
Main Stream:
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720), 50fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720), 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
API:
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users, 3 levels: Administrator, Operator and User
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE 8+, Chrome 31+, Firefox 30+, Safari 8.0+ web browser
Security Measures:
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering
Alarm Linkage:
Preset, Patrol Scan, Pattern Scan, Memory Card Video Recording, Trigger Recording, E-Map, VCA Capture, Upload to FTP, Send Email, etc.
Alarm Output:
1-ch alarm output
Alarm Input:
2-ch alarm input
Audio Input:
1-ch audio input
Audio Output:
1-ch audio output
Network Interface:
1 RJ45 10 M/100 M Ethernet Interface, Hi-PoE
Storage:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 128 GB, NAS (NPS, SMB/ CIPS), ANR
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG,H.264 with Baseline/Main/High Profile
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
SVC:
Support
3D DNR:
Support
AGC:
Auto/Manual
Regional Exposure:
Support
Regional Focus:
Support
Image Sensor:
1/1.9" progressive scan CMOS
Min. Illumination:
Color: 0.005 Lux @(F1.5, AGC ON),B/W: 0.002 Lux @(F1.5, AGC ON),0 Lux with IR
White Balance:
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Shutter Time:
50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
Day & Night:
IR cut filter
Digital Zoom:
16×
Privacy Mask:
8 programmable privacy masks
Focus Mode:
Auto/Semi-automatic/Manual
BLC:
Support
HLC:
Support
Optical Defog:
Support
Digital Defog:
Support
EIS:
Support
Digital WDR:
Support
IR Distance:
150 m
Smart IR:
Support
IR Control:
IR brightness and angle are intelligently adjustable according to the scenes.
Movement Range (Pan:
360° endless
Pan Speed:
Configurable, from 0.1°/s to 160°/s, Preset Speed: 240°/s
Movement Range (Tilt:
From -15° to 90° (Auto Flip)
Tilt Speed:
Configurable, from 0.1°/s to 120°/s, Preset Speed: 200°/s
Proportional Zoom:
Support
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Support
Park Action:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Status Display:
Support
Preset Freezing:
Support
Scheduled Task:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output
Basic Event Detection:
Motion Detection, Video Tampering, Alarm Input, Alarm Output, Exception
Smart Detection:
Audio Exception Detection, Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection
Smart Tracking:
Support
Smart Record:
ANR (Automatic Network Replenishment), Dual-VCA
ROI:
Main stream, sub-stream and third stream respectively support four fixed areas.
Dimensions:
Φ 220 mm × 353.4 mm (Φ 8.66" × 13.91")
Weight:
Approx. 4.5 kg (9.92 lb)
Protection Level:
IP66, IK10 (excluding glass window), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power:
24 VAC & Hi-PoE, Max.: 40 W,IR: 19 W
Working Temperature:
Outdoor: -30°C to 65°C (-22°F to 149°F)
Working Humidity:
≤ 90%
