FOV:
Horizontal field of view: 57.6° to 2.5° (Wide-Tele),Vertical field of view: 34.4° to 1.4° (Wide-Tele),Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
Zoom Speed:
Approx. 3.6 s (optical lens, wide-tele)
Working Distance:
10 mm to 1500 mm (wide-tele)
Aperture Range:
F1.6 to F3.5
Focal Length:
4.8 mm to 120 mm, 25× optical zoom
Image Enhancement:
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Max. Resolution:
1920 × 1080
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),50fps (1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720),60fps (1280 × 960, 1280 × 720)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Network Storage:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
API:
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Security Measures:
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Alarm Linkage:
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Trigger Recording, Trigger Alarm Output, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Alarm Output:
1-ch alarm output
Alarm Input:
2-ch alarm input
Audio Input:
1-ch audio input, 2 to 2.4 V[p-p], 1 KΩ ± 10%
Audio Output:
1-ch audio output, line level, impedance: 600 Ω
Network Interface:
1 RJ45 10 M/100 M Ethernet, Hi-PoE
H.264:
Support
H.265:
Support
H.264 Type:
Baseline Profile/Main Profile/High Profile
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG
H.265 Type:
Baseline Profile/Main Profile/High Profile
Video Bitrate:
32 Kbps to 16384 Kbps
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bitrate:
G.711alaw/G.711ulaw: 64 Kbps,G.722.1/G.726: 16 Kbps,MP212/PCM: 32 Kbps to 160 Kbps
SVC:
Support
Image Sensor:
1/2.8" progressive scan CMOS
Min. Illumination:
Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001Lux @(F1.6, AGC ON),0 Lux with IR
White Balance:
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Gain:
Auto/Manual
Shutter Time:
50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s
Day & Night:
IR Cut Filter
Digital Zoom:
16×
Privacy Mask:
24 programmable privacy masks
Focus Mode:
Auto/Semi-automatic/Manual
WDR:
120 dB WDR
IR Distance:
150 m
Smart IR:
Support
Movement Range (Pan:
360° endless
Pan Speed:
Configurable, from 0.1°/s to 120°/s,Preset speed: 120°/s
Movement Range (Tilt:
From -15° to 90° (auto-flip)
Tilt Speed:
Configurable, from 0.1°/s to 80°/s,Preset Speed: 80°/s
Proportional Zoom:
Support
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Support
Park Action:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
3D Positioning:
Support
PTZ Status Display:
Support
Preset Freezing:
Support
Scheduled Task:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output
Basic Event Detection:
Motion Detection, Video Tampering Detection, Exception
Smart Detection:
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
Smart Record:
ANR (Automatic Network Replenishment), Dual-VCA
ROI:
Main stream, sub-stream, and third stream respectively support four fixed areas.
Material:
ADC 12, PC, PC+10% GF
Dimensions:
Φ 208 mm × 345 mm (Φ 8.19" × 13.58")
Weight:
Approx. 3.3 kg (7.28 lb)
Protection Level:
IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Power:
24 VAC and Hi-PoE,Max.: 30 W (Max. 10 W for IR)
Working Temperature:
-30°C to 65°C (-22°F to 149°F)
Working Humidity:
≤ 90%
