Type:
Dome
Frame Rate:
30fps
Imaging Device:
1/2.8" 2MP CMOS
Resolution:
2MP
Max. Framerate:
60fps
Min. Illumination:
0.055 Lux color
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
2.8mm fixed focal
Max. Aperture Ratio:
F2.0
Angular Field of View:
H: 112˚, V: 62˚, D: 130˚
Min. Object Distance:
0.2m(0.66ft)
Lens Type:
Fixed
Pan / Tilt / Rotate Range:
0˚~353˚ / 0˚~59˚ / 0˚~353˚
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(Electrical)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
150dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support
Defog:
Support
Motion Detection:
8ea, 8point Polygonal zones
Privacy Masking:
32ea, 4point Quadrangle zones; - Color : Gray, Green, Red, Blue, Black, White; - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90˚/270˚)
Analytics:
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line
Business Intelligence:
People counting, Queue management, Heatmap
Alarm Triggers:
Analytics, Network disconnect
Alarm Events:
File upload via FTP and e-mail; Notification via e-mail; SD/SDHC/SDXC or NAS recording at event triggers; DPTZ preset
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
Security:
HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access log; 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
Webpage Language:
English, Korean, French, German, Spanish, +more
Edge Storage:
Micro SD/SDHC/SDXC 1slot 256GB
RAM:
1024MB RAM, 256MB Flash
Operating Temperature / Humidity:
-30°C to +55°C /
Storage Temperature / Humidity:
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
PoE(IEEE802.3af, Class3)
Power (Max:
PoE : Max 6.5W
Color / Material:
Ivory / Metal
Product Dimensions / Weight:
Ø112.8x63.7mm(4.44"x2.51"), 420g(0.93 lb)
Detect (25PPM/ 8PPF:
25.9m(84.98ft)
Observe (63PPM/ 19PPF:
10.4m(33.99ft)
Recognize (125PPM/ 38PPF:
5.2m(17.00ft)
Identify (250PPM/ 76PPF:
2.6m(8.50ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Features:
WDR
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
0.2m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
0.93
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
3-year warranty
Poe Power:
PoE (802.3af)
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Lens:
Ethernet Rate:
RJ-45(10/100BASE-T)
Application:
ONVIF S,G,T
Operating System:
/FirmwareProtect Encryptedfirmware,Secureboot,Signedfirmware
Memory:
RAM 1GB
Storage:
256MB
Material:
Metal
Certifications:
&Standards
Environment:
IEC60529IP66,IEC62262IK10,NEMA250type4X
