Type:
PTZ
Imaging Device:
1/2.8" CMOS
Resolution:
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.015Lux(F1.4, 1/30sec); BW: 0.0015Lux(F1.4, 1/30sec)
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB type B, 1280x720 for installation
Focal Length (Zoom Ratio:
2.8~12mm(4.3x) zoom (digital 32x, total 137.6x zoom)
Max. Aperture Ratio:
F1.4
Angular Field of View:
H: 119.5˚(Wide)~27.9˚(Tele); V: 62.8˚(Wide)~15.7˚(Tele); D: 142.1˚(Wide)~32.0˚(Tele)
Min. Object Distance:
Wide: 1.5m(4.92ft) / Tele: 2m(6.56ft)
Focus Control:
Oneshot AF
Lens Type:
DC auto iris
Pan Range:
0˚ ~ 350˚
Pan Speed:
0.1˚/sec ~60˚/sec
Tilt Range:
0˚ ~90˚
Tilt Speed:
0.1˚/sec ~60˚/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.5˚
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
150dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, 4point quadrangle zones; - Color: Grey/Green/Red/Blue/Black/White; - Solid/Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification
Serial Interface:
RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell)
Alarm Inputs/Outputs:
Input 1ea / Output 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail; Notification via e-mail; SD/SDHC/SDXC or NAS recording at event triggers; Alarm output; PTZ Preset
Audio In:
Selectable(mic in/line in); Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
Auto Tracking:
Support
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable; G.726(ADPCM) 8KHz, G.711 8KHz; G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps; AAC-LC: 48Kbps at 16KHz
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast), NTCIP 1205
Security:
HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access log; 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 2slot 512GB
RAM:
1GB RAM, 256MB Flash
Operating Temperature / Humidity:
-30°C~+55°C (-22°F~+131°F) / Less than 90% RH
Storage Temperature / Humidity:
-30°C~+60°C (-22°F~+140°F) / Less than 90% RH
Certification:
IP66, IK10
Input Voltage:
DC12V, PoE(IEEE802.3af, Class3)
Power (Max:
DC12V: Max. 8.6W; PoE : Max. 9.6W
Color / Material:
Ivory / Aluminum
Product Dimensions / Weight:
ø136x106mm(5.35x4.17"), 780g(1.72 lb)
Hanging Mount (Dome:
SBP-301HM5
Backbox:
SBV-136B
Ceiling Mount (Assy:
SBP-300CM
Wall Mount:
SBP-300WM1, SBP-300WM
Pole Mount:
SBP-300PM1
In-ceiling Mount:
SHD-3000F3
Parapet Mount:
SBP-300LM
Corner Mount:
SBP-300KM1
Other Compatible Models:
SPB-PTZ71(Smoked Dome Cover)
Detect (25PPM/ 8PPF:
Wide: 22.4m(73.47ft) / Tele: 154.6m(507.18ft)
Observe (63PPM/ 19PPF:
Wide: 9.0m(29.39ft) / Tele: 61.8m(202.87ft)
Recognize (125PPM/ 38PPF:
Wide: 4.5m(14.69ft) / Tele: 30.9m(101.44ft)
Identify (250PPM/ 76PPF:
Wide: 2.2m(7.35ft) / Tele: 15.5m(50.72ft)
Product Type:
PTZ
Connectivity:
Wired
IP Rating:
IP66
Features:
WDR
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
PTZ
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
1.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
1.72
PTZ Range:
0˚ ~ 350˚
Housing Color:
White
environment_rating:
Outdoor
warranty:
3-year warranty
