Hanwha SBP-302CMAS Telescopic Pendant Mount with Swivel Adaptor
The SBP-302CMAS is a professional-grade telescopic pendant mount designed for fixed and adjustable camera positioning in indoor and outdoor surveillance installations. Its adjustable height and precision swivel capability solve a common integration challenge: mounting cameras at the correct elevation and angle without costly structural modifications or multiple mounting hardware SKUs.
Key Features
- Telescopic Height Adjustment (4.5 to 8 feet): Extends to accommodate standard warehouse and retail ceiling heights without requiring custom conduit runs or additional support brackets. Field-adjustable length means you can set the exact drop needed for optimal coverage angle — avoiding the cost and delay of ordering multiple fixed-length mounts.
- Swivel Adaptor with ±45° Pivot Range: Allows precise camera aiming in either direction from the vertical centerline. Critical for narrow aisles, corner coverage, or adjusting aim after installation without remounting hardware.
- Aluminum and Steel Hybrid Construction: Combines lightweight aluminum tubing (easier to handle during installation) with steel reinforcement at stress points. The combination resists corrosion in damp environments — warehouses, cold storage, light outdoor covered areas — without the full weight penalty of all-steel mounts.
- 1.5" NPT Thread Compatibility: Standard male NPT connection integrates directly with Hanwha hanging mount systems and most industry-standard camera housings. This removes the need for adapter plates or custom brackets in mixed-brand deployments.
- Hanwha Hanging Mount Compatible: Seamless integration with Hanwha IP cameras and housing ecosystems reduces parts inventory and simplifies procurement when specifying Hanwha surveillance systems.
- No Additional Hardware Required for Height Adjustment: Telescopic design allows on-site length tuning; no wrenches, spacers, or replacement tubes needed. Deployment speed matters in large rollouts — this cuts installation time per camera.
Integration and Compatibility
The SBP-302CMAS integrates with Hanwha camera housings via the 1.5" NPT thread standard. It is compatible with pendant-mounted camera form factors — typically compact box, turret, or compact dome housings rated for pendant suspension. Verify that your selected camera housing includes an NPT-threaded pendant mount plate or adapter; some Hanwha models include this as standard, while others require a separate bracket.
For mixed-brand deployments, confirm NPT thread compatibility on your housing before ordering. The mount itself does not include a quick-release or ball joint — the swivel adaptor provides the rotational freedom; if you need pan/tilt adjustment, pair this with a motorized head or consider a PTZ camera mounted on a fixed bracket instead.
Installation Notes
Pendant mounts hang from ceiling structure, conduit, or overhead rails. The 4.5–8 ft range suits standard 8–10 ft interior ceilings and covered outdoor structures. For ceilings higher than 8 feet, you will need a fixed or custom conduit extension. The aluminum/steel frame is light enough for two-person rigging but sturdy enough for medium-weight housings (verify your camera housing weight against the mount's load rating in the full datasheet).
The swivel adaptor permits field aiming; once locked, it holds position without drift. Ensure the camera housing is properly balanced before tightening the swivel lock — an unbalanced load may strain the pivot point over time, particularly in areas with vibration (near machinery, traffic, HVAC units).
When to Choose a Different Approach
If your ceiling height exceeds 8 feet, consider a fixed-length pendant or switch to a wall-mount or corner mount. If you require motorized pan/tilt adjustment, integrate a motorized PTZ head rather than relying on manual swivel aiming. For outdoor installations with constant weather exposure or high-vibration environments (industrial plants with heavy machinery), verify the mount's load rating and environmental testing in the full technical documentation.
Frequently Asked Questions
Q: What is the weight capacity of the SBP-302CMAS?
A: Consult the full datasheet for the precise load rating. The aluminum/steel construction supports typical surveillance housings; confirm your camera housing weight against the specification before installation.
Q: Can I use the SBP-302CMAS outdoors?
A: The aluminum and steel frame resists corrosion and environmental stress, making it suitable for covered outdoor areas (eaves, overhangs, covered parking). For direct rain exposure or high salt-air environments, verify the mount's environmental rating and consider additional protective coating if needed.
Q: Is the telescopic adjustment tool-free?
A: Yes. The telescopic design allows you to extend or retract the mount in the field without additional hardware, then lock it at the desired height.
Q: Will the SBP-302CMAS work with non-Hanwha cameras?
A: The 1.5" NPT thread is a standard connection interface. It will integrate with any camera housing that includes a matching NPT-threaded pendant mount plate. Confirm thread compatibility before purchase.
Q: What is the swivel angle range?
A: The swivel adaptor permits ±45° rotation — up to 45 degrees in either direction from the vertical centerline, allowing you to angle the camera left, right, or straight down without remounting.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The SBP-302CMAS solves a real integration friction point: height variability across installations. Most pendant mounts come in fixed lengths — you order the wrong one, you eat the restocking delay or you fabricate a spacer. The telescopic range of 4.5 to 8 feet covers the vast majority of standard warehouse and retail ceiling heights in a single SKU, cutting procurement complexity and installation rework.
Technical Highlights:
- Aluminum/Steel Hybrid Frame: Reduces weight compared to all-steel mounts, making two-person installation feasible without lifting equipment, while maintaining structural integrity at stress points. Corrosion resistance suits damp environments — cold storage, outdoor covered areas — without requiring stainless-steel cost.
- ±45° Swivel Adaptor: Delivers field aiming flexibility without motorized complexity. In narrow aisles or corner installations, this eliminates the need to remount or order a second bracket. Once set, the pivot holds position — no drift under vibration if properly balanced.
- 1.5" NPT Thread Standard: Direct compatibility with Hanwha housings and broad interoperability with third-party pendant-mount-capable housings. Reduces the number of adapter plates you need to stock on a large rollout.
Deployment Considerations:
- Verify camera housing weight against the mount load rating before final installation. Unbalanced loads on the swivel pivot can cause creep over months, especially near machinery or high-vibration areas.
- The 8-foot maximum reach suits standard interior ceilings; if your coverage area has taller structures or you need longer drops, a fixed-length pendant or wall-mount bracket becomes necessary. Plan your camera placement first; do not force an oversized camera down a too-short mount.
- Confirm that your camera housing includes an NPT-threaded pendant plate. Some Hanwha housings include this; others require a separate bracket purchase — verify before ordering to avoid integration delays.
The SBP-302CMAS is a strong fit for warehouse networks, retail floor deployments, and office interiors where pendant mounting from existing ceiling structure is feasible and ceiling heights fall in the 8–10 ft range. It reduces parts inventory, simplifies procurement, and cuts installation labor on multi-camera jobs — exactly what you want in a standardized mounting accessory.
