Panduit UTP28X6INVL TX6A-28 Cat6A 6-Inch Patch Cord

The Panduit UTP28X6INVL is a 6-inch Cat6A UTP patch cord engineered for high-density datacenter and server room deployments where cable management, airflow, and rapid provisioning matter. Built with 28 AWG solid conductors in a compact 4.7mm diameter jacket, this violet patch cord delivers full 10GBASE-T performance while simplifying installation in congested racks, zero-U cable managers, and top-of-rack switch environments. The tangle-free latch design prevents snags during moves, adds, and changes, and each cord ships with pre-installed RapidID barcodes for automated port mapping and asset tracking. CM/LSZH dual-rated for commercial and low-smoke installations.

Key Features

• 28 AWG compact design (4.7mm OD) reduces bundle diameter and improves airflow in high-density racks
• 6-inch length ideal for server-to-switch, patch-panel-to-switch, and blade-chassis interconnects
• 100% factory tested for wire map, NEXT, and return loss; centered de-embedded plug with integral pair manager
• Patented tangle-free latch streamlines MACs and prevents cable damage during removal
• RapidID pre-installed barcodes enable one-scan port documentation with Panduit RapidID software
• CM/LSZH dual flammability rating supports NEC Article 800 and low-smoke/low-halogen requirements
• Supports IEEE 802.3af/at PoE (48-cable bundles) and 802.3bt Type 3 / Type 4 (24-cable bundles)

The 28 AWG conductor gauge is the defining advantage in datacenter top-of-rack and blade-server environments where you're managing 40+ connections per rack unit. Standard 24 AWG patch cords create stiff, bulky bundles that block airflow and stress RJ45 ports; this TX6A-28 cord's 4.7mm diameter is 35% smaller than typical Cat6A patch cords, allowing you to route more cables through zero-U managers, maintain front-to-back airflow, and reduce the force on modular plugs during insertion. The solid 28 AWG conductors (not stranded) deliver consistent impedance across the 6-inch length, and the centered de-embedded plug geometry with integral pair manager ensures the cable meets Cat6A alien crosstalk (ANEXT) limits even in 48-cable bundles running 10GBASE-T at full 10 Gbps throughput. Every cord is individually tested for wire map, NEXT, and return loss before shipment—test reports available on request for customers with TIA-568.2-D acceptance testing requirements.

The tangle-free latch isn't marketing—it's a retention clip redesign that prevents the latch from catching on adjacent cables when you pull a cord from a dense switch port block. Standard RJ45 latches snag every cable they pass, forcing you to work one-handed with a screwdriver to depress latches while pulling; Panduit's latch profile sits flush and releases with a single thumb press, cutting MAC time by 40% in real-world testing. The violet jacket is a common datacenter standard for storage networks, secondary VLANs, or cross-connect trunks—check your organization's TIA-606-B color code before ordering. RapidID barcodes are silk-screened directly on the jacket near each plug; scan once during installation to auto-populate switch port, MAC address, and device hostname in RapidID's web dashboard, eliminating manual spreadsheet documentation and the errors that come with it.

PoE support covers the full 802.3bt Type 4 spec (90W) when deployed in 24-cable bundles, making this cord suitable for high-power PoE++ devices like PTZ cameras, IP access points with integrated switches, and LED lighting controllers—just respect the bundle de-rating per IEEE 802.3bt Table 104-5. The CM/LSZH dual rating means one SKU covers NEC Article 800 commercial riser/general-purpose installations and European/APAC low-smoke installations under IEC 60332-3 and IEC 61034—no need to stock separate CM and LSZH SKUs for multi-region deployments. Meets ANSI/TIA-1096-A (formerly FCC Part 68 registration) and IEC 60603-7 for plug/jack interoperability. Carton quantity is 10 pieces; violet jacket is not available in other lengths—see Panduit's TX6A-28 family for 1 ft, 3 ft, and 7 ft variants in the same 28 AWG construction.
