Speco Technologies V5B1M 5MP HD-TVI Motorized Bullet Camera
Overview
The Speco Technologies V5B1M is a 5MP HD-TVI bullet camera built around a 2.8-12mm motorized lens — the kind of remote-adjustable optics you want when a camera is mounted 15 feet up a pole and you're not climbing a ladder to refocus it after a coverage-angle change. At 2560x1936 resolution, the V5B1M gives you meaningfully more pixel density than a standard 1080p analog camera, which matters when you're trying to pull a face or plate off a recording after the fact rather than just confirming "someone was there." This is an HD-TVI camera, so it runs on coax over existing analog cable runs — a practical fit for upgrading legacy CCTV infrastructure without pulling new cable to every camera position.
Key Features
- 5MP Resolution (2560x1936): Roughly 2.3x the pixel count of 1080p, which translates directly into more usable detail when you digitally zoom into recorded footage — the difference between identifying a vehicle and just knowing one drove by.
- 2.8-12mm Motorized Zoom Lens (4x Optical): Adjust field of view remotely from the head end instead of physically re-aiming the camera. On a bullet camera mounted at height, that saves a truck roll every time coverage requirements shift.
- 165' IR Range: Rated to deliver usable night imaging out to 165 feet, which covers a decent stretch of parking lot, perimeter fence line, or loading dock approach without relying on separate illuminators.
- 0 Lux with IR On: Full darkness is not a blind spot — the camera switches to IR-assisted black-and-white imaging when ambient light drops to zero, which is the baseline requirement for any true 24/7 perimeter camera.
- 0.01 Lux Color Sensitivity (F1.2, AGC On): In dusk, dawn, or security-lit conditions, the V5B1M can hold color imaging well below what a standard-sensitivity camera can manage — useful for distinguishing uniform colors or vehicle colors in low-light incident review.
- Low Power Draw — ≤1W (IR Off) / ≤6W (IR On): Power consumption stays modest even with IR illuminators active, which keeps a multi-camera coax/power run from overloading a shared power supply at the head end.
- -22°F to 122°F Operating Range: Rated for real outdoor extremes — this is a camera you can mount on an exterior wall in a northern winter or a southern summer roofline without a separate enclosure.
- 10%-90% Relative Humidity Tolerance: Built to handle humid coastal or seasonal-swing climates without condensation-driven failure inside the housing.
- 12VDC Power Input: Standard analog-camera power input, compatible with typical CCTV power supplies and multi-output DC power boxes already common in coax installs.
- NDAA Compliance: Meets NDAA Section 889 sourcing requirements, which matters directly for government, municipal, school district, and federal-contractor deployments where non-compliant hardware is a disqualifying issue, not a preference.
- Compact Bullet Housing (8.6" L x 3.2" W x 3.2" H): A traditional bullet form factor sized for straightforward wall or pole mounting with a visible sun-shield profile that also serves as a visual deterrent.
Integration & Compatibility
As an HD-TVI camera, the V5B1M is designed to connect to HD-TVI-compatible DVRs over coax, making it a direct fit for sites migrating from analog CCTV without a full cable rip-and-replace. If you're planning a broader system around this camera, pairing it with the right network video recorders or HD-TVI-capable DVR matters more than any single camera spec — resolution and channel support on the recorder side need to match what the V5B1M is capturing, or you lose the benefit of the 5MP sensor at the recording layer. For sites running a mix of coax and IP cameras, review a camera selection guide before finalizing the head-end hardware so channel count and storage budget are sized correctly from the start.
What's in the Box
The V5B1M ships as a complete bullet camera unit ready for mounting and coax connection; consult the included documentation for connector and mounting hardware specifics at installation.
Frequently Asked Questions
Q: Is the V5B1M NDAA compliant?
A: Yes, the V5B1M meets NDAA compliance requirements, making it eligible for government, municipal, and federal-contractor installations that require NDAA-compliant video hardware.
Q: What is the maximum IR range on the V5B1M?
A: The V5B1M is rated for an IR range of up to 165 feet.
Q: Does the V5B1M have a motorized lens?
A: Yes, it uses a 2.8-12mm motorized lens with 4x optical zoom, adjustable remotely without physically repositioning the camera.
Q: What is the warranty on the V5B1M?
A: The V5B1M carries a 5-year manufacturer warranty.
Q: What resolution does the V5B1M record at?
A: The V5B1M records at 5MP (2560x1936) resolution over HD-TVI.
Q: Can the V5B1M be installed outdoors?
A: Yes, it's rated for an operating temperature range of -22°F to 122°F and 10%-90% relative humidity, suited to exterior wall or pole mounting.
The V5B1M is one of those cameras that earns its keep on the lens alone — a 2.8-12mm motorized zoom on a 5MP HD-TVI bullet means you can fine-tune field of view from the DVR menu after mounting, instead of guessing the angle on a ladder before you've seen the recorded image.
Technical Highlights:
- 5MP Sensor (2560x1936): Delivers roughly double the resolution of 1080p analog, which is the difference between a usable plate capture and a blurry smear when you crop into an HD-TVI recording after an incident.
- 165' IR Range with 0 Lux Cutoff: Full-darkness imaging out to 165 feet covers a realistic perimeter or lot-edge distance without adding external illuminators to the BOM.
- ≤6W Power Draw with IR Active: Even with IR illuminators running, draw stays under 6W — light enough that a standard 12VDC multi-camera power supply won't need upsizing for a few of these on one circuit.
Deployment Considerations:
- This is HD-TVI, not IP — confirm your DVR supports HD-TVI signal input before specifying the V5B1M into a mixed-technology system.
- The motorized lens is a maintenance advantage but also means there's a moving part in the optical path; factor that into long-term service expectations versus a fixed-lens bullet.
Specify the V5B1M where you're extending or upgrading an existing coax-run analog system and need better low-light and resolution performance without rewiring the site for IP — a strip mall perimeter or a warehouse loading dock already wired for HD-TVI are both good fits.
