Description

StarTech N6PAT50YLS 50ft Yellow Slim Cat6 Ethernet Cable

Overview

This 50-foot yellow, slim Cat6 Ethernet cable, model N6PAT50YLS, is engineered for high-power network devices and demanding environments. Its 28AWG construction and UTP design support data rates up to 10 Gbps, while the LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces. The snagless connectors simplify installation, and the cable is rated for 100W PoE++ (IEEE 802.3bt Type 4), making it suitable for powering high-demand equipment like PTZ cameras or wireless access points without needing separate power injectors.

Compatibility

This cable is compatible with any network device requiring a Cat6 Ethernet connection and supporting 100W PoE++ (IEEE 802.3bt Type 4). It is suitable for use with StarTech.com's line of PoE-powered devices, as well as third-party IP cameras, access points, and other network hardware that draws up to 100W of power. The TIA/EIA-568-B.1-2001 T568B wiring standard ensures broad interoperability with standard network infrastructure.

Installation Notes

The cable features snagless connectors to prevent damage to the locking tab during installation. Its slim 0.1-inch outer diameter and 28AWG stranded copper construction offer flexibility for routing in tight spaces. The operating temperature range is 10°C to 60°C (50°F to 140°F), and storage temperature is -20°C to 60°C (-4°F to 140°F). Humidity tolerance is 10% to 80% RH.

What's in the Box

  • 1x 50 ft Yellow Slim Cat6 Ethernet Cable
Specifications
Cable Length: 50.0 ft
Cable OD: 0.1 in
Wire Gauge: 28 AWG
Conductor Type: Stranded Copper
Connector Plating: Gold
Cable Jacket Material: Low Smoke Zero Halogen
Fire Rating: LSZH Rated
Wiring Standard: TIA/EIA-568-B.1-2001 T568B
Maximum Data Transfer Rate: 10 Gbps
Cable Rating: CAT6 - 250 MHz
PoE Rating: 100W PoE++
PoE Standard: IEEE 802.3bt Type 4
Operating Temperature: 10C ~ 60C
Storage Temperature: -20C ~ 60C
Humidity: 10% ~ 80%
Color: Yellow
Connector Style: Straight
Product Weight: 8.9 oz
Number of Conductors: 4 pair UTP
Brand: StarTech
MPN: N6PAT50YLS
Type: Ethernet Cable
Connectivity: Ethernet
Power: 100W
