Middle Atlantic 4G DEV PLT 2 DUP 2 TJ Mini Adpt G - G4047-2BBTT

Middle Atlantic G4047-2BBTT 4-Gang Cover Plate with Duplex and TracJack Mini Adapter Openings

Overview

The Middle Atlantic G4047-2BBTT is a steel 4-gang wall cover plate configured for two duplex receptacle openings and two TracJack mini adapter cutouts. In structured wiring and AV/security installations where a single faceplate needs to consolidate AC power and low-voltage connectivity — think rack room walls, equipment rooms, or in-wall consolidation points — the G4047-2BBTT provides the correct gang count and opening layout without field modification. The gray finish integrates with standard commercial wallplate aesthetics. TAA-compliant for deployments subject to federal procurement requirements.

Compatibility

Designed for use with Middle Atlantic TracJack and steel cover plate systems in 4-gang configurations. The two duplex openings accept standard Decora-style duplex receptacles. The two TracJack mini adapter slots accept Middle Atlantic TJ-series mini adapters, which support keystone-format low-voltage inserts — covering Ethernet (RJ-45), coax, HDMI, and other connector types depending on the insert selected. Fits standard 4-gang electrical boxes. Compatible with commercial wall plate and cover installations requiring mixed power and data termination at a single location. Verify box depth and wall construction before ordering — 4-gang boxes vary in depth, which affects flush-mount seating.

Installation Notes

Mount to a 4-gang electrical box using standard wallplate screws (not included — use appropriately sized 6-32 machine screws for the box type). Populate duplex openings and TracJack slots independently; the plate ships without inserts or receptacles. For TAA-compliant deployments, confirm all inserts and receptacles installed alongside this plate also meet TAA requirements — the plate itself carries the TAA designation but installed components are procured separately. Color is gray; no other color variants are documented for this model.
