2N 03369-001 IP Force 2.0 5MP Video Intercom
The 2N 03369-001 is a second-generation outdoor video intercom purpose-built for high-security access control and visitor management at entry points. It combines a 5MP sensor with Axis' ARTPEC-8 processor to run facial detection, QR code scanning, and intelligent video encoding directly on the device—eliminating the need for backend servers to handle real-time identification tasks. This architectural choice reduces latency in access workflows and cuts network bandwidth consumption, which matters when you're recording 24/7 across multiple entry points.
Key Features
- 5MP Resolution (2592 x 1944): Captures facial detail sufficient for reliable biometric matching and forensic review at typical entry distances (0.3–3 meters). The higher resolution means usable facial data persists even when a visitor stands at an angle or partially obscures their face—critical when access decisions depend on identity verification.
- ARTPEC-8 Processor with On-Device Analytics: Facial detection and QR code reading execute on the intercom itself, not on a remote server or VMS. This reduces API round-trip latency during access attempts and cuts your network overhead. You also avoid the backend compute cost of scaling analytics across dozens of intercoms.
- H.265 and H.264 Dual Compression: The device streams both codecs simultaneously, so your network video recorder or VMS can select based on storage or bandwidth constraints. H.265 reduces file sizes roughly 40–50% compared to H.264 at equivalent quality—a meaningful factor when storing weeks of intercom footage on a 1–2TB appliance.
- Adaptive Face Zooming: The device automatically detects and magnifies facial regions within the captured frame. This solves a real outdoor problem: inconsistent visitor positioning due to weather, lighting, and behavior. The zoomed frame remains usable for both live visual verification and biometric matching without operator intervention.
- QR Code Reading (1D/2D): Integrated scanner recognizes credentials on badges, mobile phones, or printed passes. Visitors tap or hold their credential; the intercom validates it on-device and triggers the access workflow directly. Eliminates manual identity confirmation and reduces visitor wait times at the door.
- Four Programmable Buttons: Customizable inputs support diverse access scenarios—call building security, transfer to specific departments, unlock a secondary gate, or initiate multi-factor authentication. Button actions integrate via standard SIP or HTTP webhooks to most modern access control systems without firmware modifications.
- Two-Way Audio: Built-in microphone and speaker enable real-time communication between the visitor and building occupant. Useful for screening deliveries, contractor verification, or directing visitors to alternate entrances during restricted hours.
- IP66 / IK10 Rating: IP66 means the device resists direct rain jets and dust ingress—suitable for permanent outdoor deployment in most climates. IK10 impact resistance protects against deliberate tampering and weather-related stress. Skip this model if you need full submersion (IP67); IP66 covers splash and spray but not underwater exposure.
- PoE+ Power (802.3at, ~15–18W): Draws moderate power via standard PoE+, so it won't strain your switch's power budget if you're running multiple intercoms. No separate power supply required; a single Ethernet cable carries both data and power to the device.
- SIP and ONVIF Compliance: Operates as a standards-compliant SIP endpoint and ONVIF Profile S/T camera. This means compatibility with VMS platforms from Milestone, Genetec, and others, plus integration with door controllers and visitor management systems from vendors like Salto and Suprema without proprietary APIs.
- Stainless Steel Faceplate: Resists corrosion in salt-air and humid environments. Sealed RJ-45 and power connectors prevent moisture ingress, extending device lifespan in coastal or wet-climate deployments.
Integration & Compatibility
The 03369-001 streams H.265 and H.264 video simultaneously to a VMS or NVR—you select codecs based on your storage or bandwidth strategy. Programmable button actions are implemented via HTTP POST or SIP events, supporting direct integration with door controllers, lock actuators, and visitor platforms. On-device QR scanning and facial detection reduce backend authentication load; verification happens at the entry point itself, not on a remote server. Operating temperature range is −30°C to 55°C, adequate for most climate zones except extreme polar or desert installations.
When to Choose a Different Model
If you need a higher megapixel count for longer-distance facial identification (beyond 3 meters), explore the higher-resolution variant in the 2N IP Force product line. If you don't need QR code scanning or on-device facial detection, consider a simpler outdoor intercom or video doorbell to reduce licensing costs. If interior mounting is the primary use case, evaluate indoor-rated models to avoid over-specifying environmental ratings.
Frequently Asked Questions
Q: Can the 03369-001 trigger door locks directly?
A: No. The intercom outputs relay signals or SIP/HTTP events to an access control panel or door controller, which then triggers the lock. You'll need a compatible access control system or relay module to complete the door actuation workflow.
Q: Does the 03369-001 work with Milestone XProtect or Genetec Clearance?
A: Yes. The device is ONVIF Profile S/T compliant and operates as a standard SIP endpoint, making it compatible with most modern VMS platforms. Consult your VMS vendor's camera compatibility list to confirm specific firmware versions and any credential-scanning plugin requirements.
Q: What's the maximum QR code read distance?
A: The integrated scanner handles typical credential distances—roughly 10–20 cm (4–8 inches) for standard badge-size QR codes. Distance varies with code size and lighting; test with your credential format before final installation.
Q: Is the 03369-001 rated for submersion or fully underwater deployment?
A: No. IP66 protects against jets and splashing, but not submersion. If the intercom may be submerged, consult 2N for IP67-rated alternatives or protective enclosures.
Q: What's the warranty period on the 03369-001?
A: Refer to your sales documentation or contact the equipment vendor for warranty terms. Standard manufacturer coverage applies; extended plans may be available.
Q: Does the ARTPEC-8 processor require licensing for facial detection or QR scanning?
A: On-device facial detection and QR code reading are built into the 03369-001 and do not require per-camera licensing. Any analytics features running on a separate VMS or backend system may require separate licenses depending on your software contract.
James EverettPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The 2N 03369-001 is a solid fit if you're deploying access control at multiple entry points and want to offload biometric and credential processing away from backend servers. The ARTPEC-8 processor running on-device facial detection and QR code scanning is the real differentiator here—it cuts API calls during peak foot traffic and reduces your VMS licensing burden if you're running facial analytics at scale. That matters when you're tying the intercom into a large access control matrix.
Technical Highlights:
- H.265 Compression with 40–50% bandwidth reduction: If you're recording 24/7 on a two-camera intercom deployment, switching from H.264 to H.265 saves enough storage to extend retention by a week or more on a standard 2TB NVR—real money if you're managing the storage footprint.
- Adaptive Face Zooming: The device automatically magnifies facial regions in the frame, so you don't lose biometric detail when a visitor is standing off-center or partially in shadow. This is less obvious than raw megapixels, but it directly improves facial matching success rates in real-world conditions.
- IP66 + IK10 ratings for outdoor permanence: The combination means the device handles salt spray, rain jets, and deliberate impact without protective enclosures. Test the sealed RJ-45 connectors during installation—ensure they're fully seated to prevent water ingress over months of exposure.
- PoE+ at 15–18W: Moderate power draw, so you won't overload a standard 95W PoE+ switch even if you're running four intercoms on the same uplink. Use a PoE+ injector or dedicated intercom power module if your switch is already at capacity.
Deployment Considerations:
- The intercom does not trigger locks directly—you must integrate it with an access control panel or door controller via relay signals or SIP/HTTP webhooks. Plan for that middleware in your system architecture, and budget for integration testing with your chosen access control vendor.
- QR code reading works well at 10–20 cm (4–8 inches) for standard badge credentials, but test with your actual credential format and expected lighting before rolling out across all entry points. Reflective or poorly printed codes may require closer distances or additional illumination.
- On-device facial detection is built into the unit—no per-camera licensing required. However, if you layer additional analytics (person counting, loitering detection) on a VMS backend, those may require separate software licenses depending on your platform.
Deploy the 03369-001 at controlled-access entry points (office lobbies, secure facilities, parking gates) where visitor screening and credential validation are core to your access workflow. The on-device processing and QR scanning make it a better fit for high-volume, time-sensitive access scenarios than basic video intercoms, but only if you can integrate it into a compatible access control or SIP-enabled door controller ecosystem. For simple call-only intercom use, a less expensive model will suffice.
