Middle Atlantic 2IN RAD FLT Elbw V4000 IV - V4011FO

Middle Atlantic V4011FO 2-In Radiused Flat Elbow for V4000 Series Raceway

Overview

The Middle Atlantic V4011FO is a 2-inch radiused full-capacity flat elbow fitting designed specifically for the V4000 series raceway system. At 8.75 in × 8.75 in with a 1.25-inch depth, this elbow handles 90-degree horizontal direction changes in your structured cable runs without kinking or pinching conductors — a common failure point when straight runs need to turn a corner in wall-mounted or surface-mounted cable management installations. The ivory finish matches the V4000 series color family, keeping finished installations looking intentional rather than patched together.

TAA compliance is confirmed for the V4011FO, which matters when your project is subject to federal procurement requirements or GSA schedule purchasing rules. Specify it with confidence on government facility, courthouse, or public-sector security deployments where country-of-origin documentation is reviewed.

Key Features

• Full-Capacity Radiused Elbow Design: The radiused geometry distributes cable bend stress across a gentle arc rather than forcing a sharp 90-degree turn. For Category 6A, fiber patch, or coax runs inside V4000 raceway, maintaining bend radius compliance directly affects long-term signal integrity — a sharp elbow fitting will cause you problems on high-frequency cabling that a radiused transition won't.
• 8.75 × 8.75 in Footprint, 1.25 in Depth: The square footprint (8.75 in × 8.75 in) accommodates the full interior capacity of the V4000 channel, meaning you're not sacrificing fill capacity at the corner transition. The 1.25-inch depth keeps the fitting flush with the raceway profile — no protrusion that would conflict with wall obstructions, conduit, or adjacent equipment panels.
• Ivory Color Match: Specified in ivory to align with the V4000 series standard color offering. Consistent finish across straight sections, elbows, and end caps is a detail that matters on client-visible installations — security operations centers, reception desks, and office corridor runs where exposed raceway is visible to building occupants.
• TAA Compliant: TAA (Trade Agreements Act) compliance is verified for this SKU. For integrators bidding on federal, state, or municipal contracts — including DoD facilities, VA hospitals, courthouses, and GSA-scheduled projects — TAA compliance on every component in the cable management system is a hard specification requirement, not optional. The V4011FO satisfies that requirement at the elbow fitting level.
• V4000 Series System Compatibility: Engineered as a matched fitting within the Middle Atlantic raceway product line, the V4011FO connects to V4000 series straight sections, tee fittings, and end caps without adapters or field modification. Mixing raceway fittings from different series or manufacturers introduces alignment gaps and fill inconsistencies — this fitting eliminates that risk at corners.
• Surface-Mount Cable Management Application: Flat elbow geometry is suited for surface-mounted raceway installations where the cable run travels along a wall or ceiling plane and needs to change horizontal direction. This is the standard scenario in structured cabling and rack infrastructure installations: runs traveling from an IDF room along a corridor wall turning a corner to reach a camera drop, reader, or access point.

Integration & Compatibility

The V4011FO is a component within the Middle Atlantic V4000 series raceway system. It is intended for use alongside V4000 straight raceway sections, tee fittings, inside corner fittings, outside corner fittings, and end caps. When planning a V4000 installation, map your direction changes in advance and specify the correct fitting type — flat elbows handle horizontal plane turns, while inside and outside corner fittings handle vertical transitions at wall-to-ceiling or wall-to-floor junctions.

For security integrators running IP camera cabling, access control wiring, or network drops inside V4000 raceway, the radiused elbow is the correct fitting at any corner where cabling fill is at or near capacity. A non-radiused or sharp-corner fitting at a full-capacity run is a code and performance risk — the V4011FO is the component that keeps the installation clean and compliant at those transition points.

TAA compliance aligns the V4011FO with project specifications that require compliant cable management components throughout. Document this fitting's TAA status in your project submittals alongside other TAA-compliant infrastructure components.

Frequently Asked Questions

Q: Is the Middle Atlantic V4011FO TAA compliant?

A: Yes. The V4011FO is confirmed TAA (Trade Agreements Act) compliant, making it suitable for federal, state, and municipal projects with country-of-origin procurement requirements.

Q: What color is the V4011FO?

A: The V4011FO is finished in ivory, matching the standard V4000 series raceway color family for a consistent appearance across straight sections and fittings.

Q: What are the dimensions of the V4011FO?

A: The V4011FO measures 8.75 inches (22.2 cm) in both height and width, with a depth of 1.25 inches (3.2 cm).

Q: What raceway series does the V4011FO fit?

A: The V4011FO is engineered for the Middle Atlantic V4000 series raceway system. It is not cross-compatible with other series without verification of channel dimensions and fitting geometry.

Q: Is this a horizontal or vertical elbow fitting?

A: The V4011FO is a flat elbow, designed for horizontal direction changes in surface-mounted raceway runs — situations where the cable run travels along a wall plane and needs to turn 90 degrees in the same plane. Vertical transitions (wall to ceiling, wall to floor) require a different fitting type.

Eden Phillips

When I'm specifying cable management for a TAA-required government security installation, the V4011FO is the fitting I call out at every horizontal corner in a V4000 raceway run. The confirmed TAA compliance on this SKU, combined with its 8.75 × 8.75-inch full-capacity geometry, means the elbow doesn't become the weak point in either your procurement submittal or your cable fill capacity at the turn.

Technical Highlights:

• Full-Capacity at 8.75 × 8.75 in: The fitting maintains the full interior cross-section of the V4000 channel through the corner transition — you don't lose fill capacity at the elbow, which matters when you're running multiple Cat6A or coax conductors to capacity.
• 1.25-in Depth Profile: At 1.25 inches deep, the fitting stays flush with the V4000 raceway profile. That matters in tight wall installations where conduit, junction boxes, or panel edges are close — no protrusion to work around.
• TAA Compliance Verified: Confirmed for this SKU. On GSA-schedule or federal facility projects, every infrastructure component needs documentation — this fitting provides it at the elbow level, not just at the major hardware.

Deployment Considerations:

• The flat elbow geometry handles horizontal plane direction changes only. If your raceway run transitions from a vertical wall surface to a horizontal ceiling or floor plane, you need the correct inside or outside corner fitting for that axis — the V4011FO won't cover that transition.
• Ivory finish is a fixed attribute on this SKU. If your installation specifies a different V4000 color variant, verify the matching elbow SKU for that color before ordering — color mismatch across fittings is a visible defect on client-facing installations.

The V4011FO is the right spec for TAA-required corridor and perimeter camera wiring runs in federal buildings, courthouses, and GSA-schedule facility upgrades where the V4000 series is the raceway standard and every component in the submittal needs documented compliance.
