Vertiv 29095VH Basic Surge Rack PDU — 15A, 8-Outlet, Horizontal 0U

Overview

The Vertiv 29095VH is a single-phase, 15A basic surge-protected rack PDU built for horizontal 0U rack mounting in equipment closets, server rooms, and structured-cabling deployments where straightforward power distribution and over-current protection matter more than remote monitoring. Eight NEMA 5-15R outlets and a NEMA L5-15P twist-lock input plug make the 29095VH a practical drop-in for standard 15A branch circuits — no rewiring, no adapters, no surprises on installation day.

This is a purpose-built unit from the Vertiv power infrastructure line: no software licensing, no network card to configure, no IP address to assign. It exists to distribute clean, surge-protected power to up to eight loads and to cut the circuit if overcurrent is detected. For integrators deploying NVR closets, access control panels, or structured wiring enclosures where simplicity and reliability beat feature count, the 29095VH delivers exactly what it promises.

Key Features

• 8x NEMA 5-15R Outlets: Enough receptacles to handle a full complement of 1U appliances — NVRs, switches, access control panels, and alarm panels — without daisy-chaining power strips. All eight outlets are rated at the unit's full 15A input, though total draw must stay within the 15A branch limit.
• NEMA L5-15P Twist-Lock Input: The locking plug eliminates accidental disconnection at the panel or UPS output. On a busy rack with cable congestion, that physical lock is meaningful — a kicked cord can't take down a whole row of equipment.
• Over-Current Protection: Built-in overcurrent protection trips before the upstream breaker, isolating the PDU load from the rest of the branch circuit. For multi-tenant or multi-zone deployments, this means a fault in one rack stays in that rack.
• Surge Protection: Basic surge suppression at the unit level reduces transient voltage exposure for connected equipment. It won't replace a proper UPS for sensitive electronics, but it adds a first line of defense against line-borne spikes in facilities without conditioned power.
• 100–120V / 50–60Hz Input Range: Covers North American standard voltage and frequency — compatible with both 60Hz US installations and 50Hz Canadian or international deployments running on North American wiring standards.
• Power LED Indicator: A single LED confirms the unit is energized. Simple, unambiguous status at a glance — useful during initial rack commissioning and fault triage without requiring a network login.
• On/Off Switch: Allows the entire PDU to be de-energized without pulling the input plug or tripping the upstream breaker. Useful during maintenance windows when you need to safely power down a full rack without disturbing adjacent circuits.
• 3.05m (10 ft) Cord Length: Long enough to reach from most rack positions to a wall panel or UPS output without extension cords. Verify your rack-to-panel distance before ordering — some deep enclosures or wall-mount cabinet-to-floor-panel runs can push against this length.
• 0U Horizontal Mounting: Occupies zero rack units of usable equipment space. Mounts in the horizontal tooling channel or on the side rail depending on the rack model, preserving every U for revenue-generating equipment.

Integration and Compatibility

The 29095VH feeds any NEMA 5-15R–plug load — standard for most 1U rack appliances, small NVRs, managed switches, access control servers, and intercom head-end units. Pair it with a rack-mount UPS upstream to add runtime protection; the L5-15P input plugs directly into most UPS NEMA L5-15R outputs without adapters.

For larger deployments running 20A circuits or requiring individual outlet metering, step up to a higher-capacity Vertiv PDU in the same family. The 29095VH is correctly scoped for single-zone, single-phase 15A environments — attempting to load it at or near 15A continuously is not recommended; standard practice is to cap continuous draw at 80% of rating (12A) to stay within code and thermal margins.

Integrators building out NVR-based surveillance closets or deploying structured cabling infrastructure will find the 29095VH fits naturally into a rack alongside PoE switches and recording appliances. For guidance on sizing rack power for multi-camera deployments, see the camera system planning guide.

Frequently Asked Questions

Q: What is the maximum current load for the Vertiv 29095VH?

A: The 29095VH is rated for 15A maximum input current at 100–120V, 50/60Hz. Per standard electrical practice, continuous loads should not exceed 80% of rating — plan for no more than 12A of continuous draw across all eight outlets.

Q: What plug type does the 29095VH use for its input connection?

A: The input plug is a NEMA L5-15P twist-lock, which connects to NEMA L5-15R receptacles commonly found on 15A UPS output panels and wall outlets. The twist-lock design prevents accidental disconnection.

Q: How many outlets does the 29095VH provide, and what type are they?

A: The unit provides 8 NEMA 5-15R outlets — the standard North American 3-prong receptacle type used by most 1U rack appliances, small switches, NVRs, and access control equipment.

Q: Does the 29095VH require any rack space (rack units)?

A: No. The 29095VH is rated 0U and mounts horizontally without consuming standard rack unit (U) space, leaving all rack positions available for equipment.

Q: Does the 29095VH include remote monitoring or outlet switching?

A: No. This is a basic PDU with no network interface, no remote monitoring, and no per-outlet switching. It provides surge protection, over-current protection, a power LED indicator, and an on/off switch — nothing more.

Q: What is the cord length on the 29095VH?

A: The input cord is 3.05 meters (approximately 10 feet). Measure your rack-to-panel distance before ordering to confirm this length is sufficient for your installation.

Karl Wilson

The 29095VH is one of those units I spec without much deliberation once I know the environment: single-phase 15A branch, eight loads or fewer, no need for per-outlet metering or remote access. The NEMA L5-15P twist-lock input is the detail I always point out first — in a packed equipment room where people are moving cables, a standard straight-blade plug will eventually get bumped loose. The L5-15P locks in place, and that simple mechanical detail has saved more than a few NVR recording gaps in facilities I've commissioned.

Technical Highlights:

• Over-Current Protection: Trips at the PDU before the upstream breaker engages, containing a fault to the affected rack rather than tripping a shared 15A circuit that may feed adjacent zones.
• 8x NEMA 5-15R at 15A Input: Eight receptacles on a single 15A feed is appropriate for low-draw appliances — NVRs, managed switches, access control head-ends. Add up your nameplate draws before you order; budget 80% of 15A (12A) for continuous operation.
• 3.05m Cord: Ten feet is enough for most rack-to-panel runs but tight if your rack is more than mid-room from the wall panel. Confirm the distance — buying a longer PDU costs less than a last-minute extension cord install.

Deployment Considerations:

• This is a basic surge PDU with no network interface — if the project spec calls for outlet-level monitoring, load shedding, or remote reboot of appliances, specify a managed Vertiv PDU instead. The 29095VH has none of those capabilities.
• The 120VA load capacity listed is a measured-at-spec-conditions figure, not a continuous operating ceiling. Run your actual load calculation; the 15A / 80% NEC guideline (12A continuous) is the governing limit in practice.

For a small NVR closet feeding four to six cameras with a managed PoE switch and an access control panel, the 29095VH fits cleanly: simple to commission, no configuration overhead, and the twist-lock input pairs directly with most 15A UPS outputs. It's the right tool for that job — and the wrong tool the moment someone asks for outlet-level control or metered monitoring.
