Hanwha HV-GS970M/18PS-R-10 16-Port Managed PoE+ Switch
The Hanwha HV-GS970M/18PS-R-10 is a 16-port Gigabit managed Ethernet switch purpose-built for IP surveillance and networked security deployments. This Layer 3 managed switch combines 16 x 10/100/1000 Base-T ports with 2 x SFP uplink ports, delivering 247W of PoE+ budget to support simultaneous power and data delivery across high-density camera installations. Engineered for integrators and IT managers deploying Hanwha network cameras and other PoE-enabled devices, the GS970M series provides enterprise-grade infrastructure for mid-to-large-scale surveillance networks.
Key Features
- 16 Gigabit PoE+ Ports — Each port delivers up to PoE+ (802.3at) power while supporting full 10/100/1000 Mbps Ethernet connectivity, eliminating the need for separate power infrastructure to connected cameras and edge devices.
- 247W Total PoE Budget — Sufficient aggregate power to run 16 high-power PoE cameras simultaneously without supplemental power supplies, streamlining deployment and reducing installation complexity.
- 2 x SFP Uplink Ports — Dual 100/1000 Base-X SFP slots provide flexible uplink options for long-distance fiber connections or redundant network paths to core infrastructure.
- Layer 3 Managed Switching — Advanced routing capabilities and traffic management enable intelligent network segmentation, quality-of-service (QoS) prioritization, and VLAN support for organized multi-camera deployments.
- Managed Form Factor — Full network management capabilities for configuration, monitoring, and troubleshooting across distributed surveillance systems.
Technical Highlights
The HV-GS970M/18PS-R-10 delivers professional-grade switching performance with robust PoE power delivery. The 247W PoE budget accommodates modern high-resolution cameras with edge analytics and thermal imaging capabilities. Layer 3 routing enables advanced network design patterns such as IP-based camera isolation, bandwidth-managed VLANs, and integrated QoS policies that prioritize video streams during congestion. The dual SFP uplink ports support both fiber backbone connections for distance and redundant Ethernet paths for network resilience.
Ideal Applications
- Mid-to-large enterprise surveillance networks with 12-16+ cameras
- Multi-building or campus-wide camera deployments requiring fiber uplinks
- High-density IP camera installations where PoE consolidation reduces infrastructure costs
- Security integrations requiring advanced VLAN segmentation and traffic management
- Hanwha network camera ecosystems leveraging managed switching for optimized performance
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Hanwha HV-GS970M/18PS-R-10 addresses a critical need in surveillance deployments: consolidated power and data delivery at scale. The 247W PoE budget is substantial but finite—careful port allocation and device power profiling ensure all connected cameras receive adequate power without bottlenecks. Layer 3 switching differentiates this unit from unmanaged alternatives, enabling integrators to build segmented camera networks with granular QoS rules.
The SFP uplink flexibility is particularly valuable in multi-site deployments where fiber reduces latency and EMI susceptibility on long backbone runs. This switch pairs well with Hanwha's own camera lineup and functions as reliable core infrastructure for organizations standardizing on managed network architecture.
