StarTech 130W AC Redundant Power Module - MCM-CHASSIS-PSU
Product images are provided for reference and may not represent the exact model, configuration, or included components.

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Get Free Pre-Sales Support Buy Design Hours ($175/hr)
Description

StarTech MCM-CHASSIS-PSU Redundant Power Module

Overview

The StarTech MCM-CHASSIS-PSU is a 130W AC redundant power module designed to ensure continuous operation for the MCM15-MEDIA- chassis. This module provides a critical backup power source, preventing downtime in surveillance or network infrastructure deployments where uninterrupted service is paramount. It's engineered for environments demanding high reliability, such as critical infrastructure monitoring or continuous data recording.

Compatibility

This redundant power module is specifically designed for the StarTech MCM15-MEDIA- chassis. It is not compatible with other chassis models or brands.

Installation Notes

The module accepts a universal input voltage range of 100-240V AC, drawing a maximum of 2.5A. It delivers a stable 48V DC output at 4.2A, providing up to 130W of power capacity. The operating and storage temperature range is -40°C to 80°C, with humidity tolerance from 10% to 95%. The unit measures 4.0 inches in length, 2.0 inches in width, and 1.0 inch in height, with a negligible weight of 0.0 lb. MTBF is rated at 50,000 hours. The product is TAA compliant.

What's in the Box

  • 1x MCM-CHASSIS-PSU Redundant Power Module
Expert Analysis
Specifications
Power Input Voltage: 100 - 240 AC
Power Input Current: 2.5 A
Power Output Voltage: 48 DC
Power Output Current: 4.2 A
Power Capacity: 130W AC
Operating Temperature: -40C to 80C
Storage Temperature: -40C to 80C
Humidity: 10~95%
Product Length: 4.0 in
Product Width: 2.0 in
Product Height: 1.0 in
Weight: 0.0 lb
Warranty: 2 Years
MTBF: 50,000 Hours
Compliance: TAA Compliant
Brand: StarTech
Brand: StarTech
MPN: MCM-CHASSIS-PSU
Type: Power Supply
Power: 240V AC
