Signamax 065-79ZXMG 1000BaseZX SFP Module

Overview

The Signamax 065-79ZXMG is a Small Form-factor Pluggable (SFP) module designed for 1000BaseZX Ethernet connections. It operates at a 1550nm wavelength, enabling data transmission up to 80 kilometers over single-mode fiber (SMF). This module is critical for extending network infrastructure across large campuses, connecting geographically dispersed facilities, or establishing long-haul links within a data center or surveillance system backbone where standard short-reach transceivers are insufficient. Its deployment ensures reliable, high-speed data flow over extended distances without requiring signal repeaters.

Compatibility

This 065-79ZXMG SFP module is compatible with any network switch, router, or media converter that supports standard un-coded SFP Multi-Source Agreement (MSA) transceivers. It is designed for use with single-mode fiber optic cabling. Specific compatibility is ensured with network devices that provide an SFP slot and support 1000BaseZX (1550nm, 80km) operation. Verify your host device's SFP port specifications for 1550nm wavelength and 80km reach support.

Installation Notes

Install the 065-79ZXMG module into an available SFP port on your network equipment. Ensure the fiber optic connector (LC type) is clean before mating it with the module's port. The module draws power from the host device's SFP slot and requires no external power source. Operate within the specified temperature range to ensure optimal performance and longevity.
