Middle Atlantic 1-GANG Duplex Recept Sect - RFB119-SD

Middle Atlantic RFB119-SD 1-Gang Duplex Receptacle Section

Overview

The Middle Atlantic RFB119-SD is a single-gang duplex receptacle section designed to populate Middle Atlantic RFB-series sectional rackmount power assemblies. The RFB119-SD drops into a standard 19-inch rackmount power frame, adding one duplex AC outlet position without requiring a separate power strip or full power unit — a practical option when a rack already runs an RFB frame but needs one more outlet section to reach the required receptacle count. Integrators building AV racks, security head-end enclosures, or network equipment bays use sections like the RFB119-SD to customize outlet density per rack without purchasing a larger fixed-outlet unit.

Compatibility

The RFB119-SD is engineered for Middle Atlantic's RFB sectional rackmount power platform. It is compatible with RFB-series sectional power frames that accept 1-gang section inserts in a 19-inch rack format. Verify your specific RFB frame model accepts the SD (single duplex) section type before ordering — Middle Atlantic offers multiple section variants (duplex, blank, USB, surge) that share the same frame footprint but are not cross-compatible with non-RFB enclosures. This section is not a standalone power unit and provides no circuit protection or switching on its own; those functions are handled by the host RFB frame assembly.

Installation Notes

Installation requires an existing RFB sectional frame already mounted in a standard 19-inch rack enclosure. The RFB119-SD slides or snaps into an open gang position within that frame per Middle Atlantic's sectional assembly procedure. No separate wiring to the section itself is required — the frame's internal bus feeds the receptacle once the section is seated. Confirm the frame's circuit capacity before adding outlet sections; additional receptacles increase potential load draw on the frame's breaker or fuse.
