Wasp 633809010385 WPL614Plus Thermal Transfer Label Printer
Overview
The Wasp 633809010385 is a 600dpi thermal transfer label printer built for warehouse receiving, pick-and-pack, and compliance labeling workflows where barcode density and label durability are non-negotiable. Thermal transfer printing means the ink ribbon bonds to the label surface — no UV fade, no moisture damage — so labels survive temperature swings and moisture exposure that would obliterate direct thermal output. The 600dpi resolution delivers crisp, consistently scannable barcodes in constrained label footprints and meets carrier or regulatory barcode density standards without compromise.
Compatibility
The WPL614Plus integrates into enterprise label management systems via USB, Ethernet, WiFi (802.11a/b/g/n), Bluetooth 4.2 combo module, Serial, or Parallel connectivity. Compatible with label design software supporting thermal transfer ribbon feeds and ZPL or equivalent barcode languages. Suitable for deployment in warehouse management systems (WMS), shipping/receiving platforms, and compliance labeling systems that require hot-swap or networked printer output.
Installation Notes
Maximum print width is 4.09 inches (104 mm); maximum print length is 1,000 inches (25,400 mm) per label. Print speed reaches 14 ips at 600dpi, enabling high-volume output without throughput bottleneck. Thermal transfer method requires ribbon supplies: standard 1-inch core, up to 600 meters long, OD maximum 90 mm. Media sensor is selectable to accommodate label gap, black mark, or continuous web detection. Storage environment ranges -40 °F to 140 °F, 10–90% non-condensing humidity — suitable for cold storage or heated warehouse staging areas. Unit weighs 34.61 lbs and occupies 10.87" W × 12.83" H × 19.76" D — allow bench or shelf space near docking stations or pick lines.
What's in the Box
- 1x WPL614Plus printer unit
- Power supply and cable
- USB and Ethernet connectivity cables
- Ribbon spool cartridge
- Setup documentation and driver software
