Bosch WALLARM AND PSU FOR AD700I 24VAC - NDA7100PA0

Bosch NDA7100PA0 Wall Mount and PSU

Overview

The Bosch NDA7100PA0 is a robust aluminum wall mount and integrated 24 VAC power supply unit designed for demanding outdoor surveillance deployments. It provides a secure mounting platform and the necessary power for compatible Bosch cameras, ensuring reliable operation in harsh environmental conditions. This unit is engineered for installations requiring a direct 24 VAC power source and a sturdy, weather-resistant enclosure, capable of withstanding extreme temperatures and physical impact.

Compatibility

This accessory is specifically designed to house and power select Bosch AD700i series cameras. Verify camera specifications for direct compatibility with the 24 VAC output provided by this unit.

Installation Notes

The NDA7100PA0 features an aluminum construction with a white powder-coated finish (RAL 9003) and is rated IP66 for dust and water ingress protection, and IK10 for impact resistance, making it suitable for exposed locations. Its operating temperature range of -60 °C to 60 °C (-76 °F to 140 °F) and 0% to 100% humidity tolerance ensure performance in extreme climates. The unit accepts 24 VAC input (±10%, 50/60 Hz) and delivers 24 VAC output at 3.15A. Mechanical certifications include UL and CE, with EMC compliance meeting FCC Part 15, ICES-003, and CE standards. Product safety adheres to EN, IEC, UL 62368-1, 60950-22, and CAN/CSA-C22.2 No. 62368-1-14. Dimensions are 523.0 mm x 216.8 mm x 185.4 mm.

What's in the Box

• 1x NDA7100PA0 Wall Mount and PSU
