Bosch Wall arm & PSU for AD7100i fiber 120VAC - NDA-7100-PA2H

Bosch NDA-7100-PA2H Wall Arm & PSU

Overview

The Bosch NDA-7100-PA2H is a robust wall-mounting arm and integrated power supply unit designed specifically for the Bosch AD7100i fiber optic camera. This accessory provides a secure mounting solution and delivers the necessary 24 VAC power from a 230 VAC input, simplifying installation in demanding environments. Its construction ensures the camera system can withstand harsh conditions, making it suitable for outdoor or industrial deployments where the camera itself might be exposed to physical impact or extreme temperatures.

Compatibility

This unit is engineered exclusively for use with the Bosch AD7100i fiber optic camera. It is not compatible with other Bosch camera models or third-party devices.

Installation Notes

The NDA-7100-PA2H operates reliably across a wide temperature range, from -60 °C to 60 °C (-76 °F to 140 °F), and supports 0% to 100% relative humidity. Its aluminum construction with a powder coat finish and sand texture provides durability. The unit is IK10 impact-rated, offering significant protection against vandalism or accidental damage. Compliance with EN 55032, EN 61000-3-2, EN 61000-3-3, FCC 47 Part 15 B, and CISPR 32 ensures electromagnetic compatibility. Product safety is certified to UL 62368-1, CAN/CSA C22.2 No. 62368-1-1, IEC 62368-1, and EN 62368-1 standards. The unit is finished in RAL 9003 Signal white.

What's in the Box

• 1x Bosch NDA-7100-PA2H Wall Arm & PSU
• 1x Mounting Template
• 1x Installation Guide
