Viking E-1600A-STIPEWP IP66 VoIP Tower Phone LED Strobe EWP

Viking Electronics E-1600A-STIPEWP VoIP Yellow Assistance Tower Phone with EWP

Overview

The Viking Electronics E-1600A-STIPEWP is a surface-mount VoIP assistance tower phone engineered for demanding outdoor and industrial environments where a standard emergency phone would fail. Built around Enhanced Weather Protection (EWP) rated to IP66, this unit pairs a high-power LED strobe/beacon with a voice announcer and auto-dialer capable of storing up to five emergency numbers — everything a safety station needs on a single telephone line, with no separate power supply required.

The yellow powder-coated steel enclosure measures just 5.25″ × 4.0″ × 2.0″, making it straightforward to surface-mount on a wall column, pillar, or post in parking structures, loading docks, campus walkways, or industrial yards where ADA-accessible emergency communication is required. If you've been searching for the E-1600A-STIPEWP (often searched as E 1600A STIPEWP), the specs below explain exactly where it fits and where a different model might serve you better.

Key Features

• IP66 Enhanced Weather Protection (EWP): The EWP rating means foam rubber gaskets and sealed gel-filled butt connector terminations prevent dust ingress and sustained high-pressure water jets from reaching internal electronics. For covered but unenclosed locations — parking garage entrances, covered loading bays, outdoor transit platforms — this is the level of protection you need. If the phone will face direct submersion, step up to an IP67-rated enclosure.
• Operating Range -30°F to 170°F: This is a notably wide thermal envelope. Most competing assistance phones top out around 130°F–140°F; the E-1600A-STIPEWP's 170°F ceiling handles west-facing metal enclosures in summer sun and equipment rooms with intermittent heat. The -30°F floor covers unheated northern parking structures without auxiliary heating elements.
• Telephone Line Powered (24V DC / 20mA minimum): Draws power directly from the telephone line — no 120V AC circuit, no PoE injector, no local UPS required. If your telco or PBX loop holds 24V DC at 20mA under load, the unit operates. This significantly simplifies conduit planning in concrete structures where pulling additional power circuits is expensive.
• Up to 5 Emergency Numbers + 2 Central Station Numbers: Program up to five emergency contacts (security desk, campus police, 911 relay) and two central monitoring station numbers independently. The separation matters: if your central station line is busy or fails, the unit can roll to an alternate without cycling through all five emergency slots.
• Up to 3 Info Numbers: Beyond emergency dialing, store up to three informational numbers — building management, parking assistance, maintenance dispatch — giving this unit a dual role as both an emergency station and a general-assistance intercom without adding a second device.
• 16-Second Voice Memory: Record a custom outgoing announcement (site name, location identifier, instructions) that plays automatically when a caller connects or when the strobe activates. On large campuses where operators handle calls from dozens of stations, a recorded location announcement eliminates ambiguity and speeds response.
• High-Power LED Strobe/Beacon: The integrated LED strobe provides visual alerting in high-ambient-noise environments — manufacturing floors, loading docks, areas near HVAC equipment — where an audio alert alone may not reach a passing worker or security patrol. LED technology means lower power draw and longer service life compared to xenon strobe alternatives.
• Steel Enclosure with Red Powder Paint Finish: The steel body with powder-coat finish resists corrosion and physical impact better than ABS plastic housings common in lower-cost tower phones. The red finish provides immediate visual identification as an emergency station at distance.
• Humidity Tolerance Up to 100% (EWP): The EWP variant handles 100% relative humidity — relevant in car washes, covered outdoor pools, cold-storage dock areas where condensation is constant. The standard version is rated 5%–95% non-condensing; specify EWP whenever the environment runs wet.

Integration & Compatibility

The E-1600A-STIPEWP connects to any standard analog telephone line or FXS port delivering a minimum 24V DC talk battery at 20mA loop current. It is compatible with analog PBX extensions, VoIP gateways with FXS output, and POTS lines. No special provisioning is required beyond loop voltage confirmation. Gel-filled butt connector terminations are included, eliminating the need for separate weatherproofing compounds on the line pair in outdoor splice points. Surface-mount installation is the only supported configuration for this model — plan your conduit entry through the back or bottom of the enclosure accordingly. For applications requiring flush or recessed mounting, a different enclosure variant should be evaluated.

Frequently Asked Questions

Q: What is the difference between the standard E-1600A and the E-1600A-STIPEWP?

A: The EWP (Enhanced Weather Protection) suffix indicates the unit is built to IP66 standards using foam rubber gaskets and sealed gel-filled butt connector terminations. The standard model is rated 5%–95% non-condensing humidity; the EWP variant handles up to 100% relative humidity and is suitable for wet, dusty, or high-pressure washdown environments.

Q: Does the E-1600A-STIPEWP require a separate power supply?

A: No. The unit is telephone line powered, drawing a minimum of 24V DC at 20mA loop current directly from the connected analog line or FXS port. No 120V AC circuit or PoE infrastructure is needed.

Q: How many emergency numbers can be programmed?

A: Up to five emergency numbers, two central station monitoring numbers, and up to three informational numbers can be stored independently.

Q: What is the operating temperature range?

A: -30°F to 170°F, which covers unheated northern installations and high-heat enclosures such as west-facing metal cabinets in direct summer sun.

Q: Is flush or recessed mounting supported?

A: No. The E-1600A-STIPEWP supports surface mount only. If recessed or flush mounting is required, a different enclosure variant should be selected.

Q: What does the 16-second voice memory do?

A: It plays a pre-recorded announcement when a caller connects — typically the station's location and instructions. On multi-station campuses, this helps dispatchers immediately identify which emergency phone is calling without relying on caller ID alone.

James Everett

The E-1600A-STIPEWP stands out in the Viking Electronics assistance phone line specifically because of its -30°F to 170°F operating range combined with IP66 EWP — a combination I don't see often enough on single-line tower phones. Most deployments I've spec'd for northern parking structures or sun-exposed industrial yards end up engineering around a phone rated to 130°F or 140°F; this unit removes that constraint without requiring a heated enclosure or auxiliary power.

Technical Highlights:

• IP66 EWP with sealed gel-filled terminations: The gel-filled butt connectors are the detail that matters in outdoor conduit runs — they waterproof the line pair at the splice point, not just the enclosure. That's a real-world reliability gain in installations where the conduit breathes moisture seasonally.
• Telephone line powered at 24V DC / 20mA minimum: Eliminates the secondary power circuit entirely. On concrete parking structures where every conduit penetration is expensive and time-consuming, this is a meaningful cost reduction in both materials and labor.
• 16-second voice memory with up to 5 emergency + 2 central station numbers: The combination of location announcement playback and independently programmed central station slots means the unit can support a tiered response protocol — local security first, then monitoring center — without custom dial-plan programming at the PBX.

Deployment Considerations:

• Verify your FXS port or analog line delivers a minimum 24V DC talk battery at 20mA under load before installation — under-voltage is the most common commissioning failure on long cable runs in large structures. Measure at the device, not at the panel.
• Surface mount only — this is a hard constraint. The 5.25″ × 4.0″ × 2.0″ footprint fits standard 4″ square single-gang surface boxes, but there is no flush-mount kit or recessed variant for this model. Plan conduit stub-out accordingly.

This unit is the right call for covered outdoor transit platforms, university campus blue-light station replacements, and industrial yard emergency stations where the combination of IP66 wet-environment tolerance, extreme temperature range, and telephone-only power makes it the lowest-complexity option to install and maintain reliably.
