Vertiv PSI5-2200RT120TAAN 2200VA/1920W Line-Interactive Rack/Tower UPS
Overview
The Vertiv PSI5-2200RT120TAAN is a 2200VA/1920W line-interactive UPS designed for edge deployments, IT closets, and surveillance infrastructure where runtime reliability and network manageability are non-negotiable. Operating at 120VAC input, it ships with an integrated Intellislot RDU120 network card — meaning remote monitoring and management are available out of the box, not an afterthought. If you're specifying power protection for a rack of NVRs, PoE switches, or edge servers, this is a unit worth a close look. Explore the full Vertiv critical power lineup for complementary solutions.
Key Features
- 2200VA / 1920W Pure Sinewave Output: Line-interactive topology with true sinewave output means sensitive electronics — variable-speed fans, active-PFC power supplies in NVRs and servers — see clean power even during brownouts. Square-wave and simulated-sinewave UPS units cause audible buzzing and shortened runtime on modern PSUs. This unit avoids that entirely.
- Rack/Tower Convertible, 2U Form Factor: Mounts in a standard 2U rack slot or stands upright as a tower — useful when a deployment starts in a wiring closet and later migrates to a proper rack. No separate tower stand kit required.
- Hot-Swappable, User-Replaceable VRLA Batteries: Battery replacement doesn't require a service call or a maintenance window that pulls protected equipment offline. Swap the battery yourself while the UPS continues to run — important for 24/7 surveillance or always-on network closets.
- Intellislot RDU120 Network Card Included: Remote UPS management, load monitoring, and graceful shutdown scripting ship in the box. Most competing units at this wattage charge extra for the network card. For distributed deployments with multiple sites, having SNMP/web access pre-installed simplifies commissioning significantly.
- Runtime Scalability via External Battery Cabinets: When the built-in battery runtime isn't enough for your longest expected outage, external battery cabinets extend runtime without replacing the UPS head unit — a meaningful cost advantage over a full-unit replacement at upgrade time.
- ANSI C62.41 Category B Surge Protection: Rated to handle the transient surge environments common in commercial and light-industrial installations — not just residential-grade protection. Relevant for deployments near HVAC equipment or in buildings with aging electrical infrastructure.
- USB Management Port: Local serial/USB management for initial configuration or as a fallback if the network card is unreachable. Compatible with Vertiv's Power Assist and Power Insight software for automated shutdown and power event logging.
- TAA Compliant: The PSI5-2200RT120TAAN carries TAA compliance, making it eligible for federal, state, and SLED procurement where Trade Agreements Act compliance is required.
Integration and Compatibility
The included RDU120 card supports SNMP, Modbus, and web-based management, integrating with network infrastructure monitoring stacks and building management systems. Power Assist software enables OS-level graceful shutdown for connected servers during extended outages. For larger surveillance deployments, pair this unit with a compatible network video recorder rack to ensure runtime coverage aligns with recording retention requirements. Reference Vertiv's Vertiv power management resources for RDU120 SNMP MIB files and firmware updates. For full UPS planning guidance, see the power protection buying guide.
Frequently Asked Questions
Q: Is the PSI5-2200RT120TAAN TAA compliant?
A: Yes. The PSI5-2200RT120TAAN carries TAA (Trade Agreements Act) compliance, making it eligible for federal and SLED procurement vehicles.
Q: Does the PSI5-2200RT120TAAN include a network management card?
A: Yes. The Intellislot RDU120 network card is included in the box — SNMP, web management, and Modbus support are available without an additional purchase.
Q: Can batteries be replaced without shutting down protected equipment?
A: Yes. The PSI5-2200RT120TAAN features user-replaceable, hot-swappable VRLA batteries. Battery swaps do not require taking the UPS or connected loads offline.
Q: What is the warranty on the PSI5-2200RT120TAAN?
A: Vertiv covers this unit with a 39-month manufacturer warranty.
Q: Can runtime be extended beyond the internal battery?
A: Yes. The PSI5-2200RT120TAAN supports external battery cabinets for runtime scalability without replacing the main UPS unit.
Q: What output waveform does the PSI5-2200RT120TAAN produce?
A: It produces a pure sinewave output — required for active-PFC power supplies found in modern servers, NVRs, and network equipment.
The PSI5-2200RT120TAAN is a solid rack power unit for anyone running a mid-density surveillance or IT edge stack — the 1920W continuous output covers a realistic mix of NVRs, managed PoE switches, and access control hardware without leaving you guessing whether the UPS will handle inrush on a cold boot. The bundled RDU120 card is the detail I'd call out first to integrators: at this price point, getting SNMP management pre-installed rather than paying separately for a network card changes the math on multi-site deployments.
Technical Highlights:
- Pure Sinewave at 1920W: Line-interactive with true sinewave output protects active-PFC power supplies in modern NVRs and servers — simulated-sinewave UPS units cause measurable efficiency loss and thermal stress on these loads.
- Hot-Swap VRLA Batteries: User-replaceable batteries mean a field tech can handle a battery refresh without scheduling downtime or dispatching a service vendor — meaningful in unmanned remote sites.
- RDU120 Network Card Included: SNMP, web interface, and Modbus in the box from day one. Pair with Power Assist or Power Insight for automated OS shutdown scripting during extended outages.
Deployment Considerations:
- The 2U rack/tower convertible form factor works in both shallow network closets and full-depth equipment racks — confirm rail kit compatibility with your specific rack before shipping.
- TAA compliance is verified for this SKU (PSI5-2200RT120TAAN), but confirm your procurement vehicle's specific TAA documentation requirements — some contracts require a certificate of conformance at the order level, not just the product spec sheet.
This unit is the right call for a surveillance equipment room or edge IT closet running 24/7 loads where battery swapability and built-in network management matter more than raw runtime — for extended outage coverage, budget external battery cabinets alongside the UPS head unit.
