Middle Atlantic UCP Module Four 1/2IN BNC Punchouts - - 1/2BNC4

Middle Atlantic 1/2BNC4 Module Four 1/2IN BNC Punchouts

Overview

The Middle Atlantic 1/2BNC4 is an expansion module designed to provide a clean, organized method for terminating and managing up to four 1/2-inch BNC coaxial video connections within a rack system. This module is crucial for professional surveillance installations where cable clutter can impede airflow, cause signal interference, and complicate maintenance. Its punchout design facilitates direct termination, reducing the need for excess cable slack and ensuring a more streamlined setup.

Compatibility

This module is engineered for use with Middle Atlantic's range of 1RU rack panels and enclosures. It is compatible with systems requiring standard BNC coaxial connections, commonly found in analog and some digital video surveillance applications. Specific compatibility extends to Middle Atlantic's:'

• Select 1RU rack panels with punchout configurations
• Universal equipment racks and enclosures

It is not designed for direct integration with IP cameras that utilize RJ45 connectors, but rather for the coaxial infrastructure that may precede or supplement an IP system.

Installation Notes

Installation involves mounting the 1/2BNC4 module into a compatible Middle Atlantic panel or enclosure. The four 1/2-inch punchouts allow for the direct passage and termination of coaxial cables. Ensure cables are properly stripped and terminated to the BNC connectors (not included) to maintain signal integrity. Proper cable management practices within the rack are essential to maximize the benefits of this module.
