Vertiv TPE-29F Top Panel Three-Fan Cooling Assembly
Overview
The Vertiv TPE-29F is a top-panel fan assembly designed to supplement airflow in compatible Vertiv precision cooling systems. Configured with three fans rated at 75 CFM each and running on 115V input, the TPE-29F provides supplemental exhaust capacity for environments where additional air movement is needed at the top of a cooling unit. For installations where rack-level thermal management is part of a broader thermal management strategy, a dedicated top-panel fan assembly like this keeps you from relying solely on the primary unit's internal air circuit.
Key Features
- Three-Fan Configuration at 75 CFM Each: Three discrete fan modules deliver airflow at the top panel, helping move heat away from the top of the enclosure. Supplemental top-panel airflow matters most in high-density deployments where the primary unit's internal fans are working near capacity.
- 115V Input: Standard North American line voltage means no special transformer or dedicated circuit is required beyond a standard 115V outlet near the unit — straightforward to provision in most data center and IDF environments.
- EC Fan Technology: The latest-generation electronically commutated (EC) fans adjust motor speed in response to demand, consuming less power at partial load than fixed-speed AC motors. In a 24/7 runtime scenario, lower idle power draw adds up across the year.
- Factory-Integrated Controls: Liebert iCOM controls are factory-installed and tested, enabling coordinated operation with the host precision cooling unit without field wiring of control interfaces — faster commissioning and fewer startup issues on site.
- Touchscreen User Interface: Local configuration, monitoring, and diagnostics are accessible via an onboard touchscreen display, so technicians can check status and adjust parameters without connecting a laptop or navigating to a remote management interface.
- Seismic-Rated Construction: IBC seismic certification means the assembly includes structural bracing for installation in seismic zones — relevant for California, Pacific Northwest, and other seismically active regions where equipment anchoring is a code requirement.
Frequently Asked Questions
Q: What is the total airflow output of the TPE-29F?
A: The TPE-29F is configured with three fans. Based on the product designation, each fan is rated at 75 CFM, for a combined nominal output of 225 CFM. Verify exact rated airflow at operating conditions against the Vertiv datasheet for your specific installation.
Q: What voltage does the TPE-29F require?
A: The TPE-29F operates on 115V input — standard North American line voltage.
Q: Does the TPE-29F include controls or monitoring?
A: Yes. Liebert iCOM controls are factory-installed and the unit includes a touchscreen display for local configuration and monitoring.
Q: Is the TPE-29F seismically rated?
A: Yes. The TPE-29F carries IBC seismic certification, meaning it includes structural bracing for installation in seismic zones.
Q: Which Vertiv precision cooling units is the TPE-29F compatible with?
A: The TPE-29F is designed for compatible Vertiv Liebert precision cooling systems. Contact Vertiv or a pre-sales engineer to confirm fitment against your specific host unit model before ordering.
The TPE-29F is a straightforward supplemental cooling add-on, but the detail that actually matters in the field is the EC fan technology: electronically commutated motors modulate speed to match load, which means partial-load power draw is significantly lower than a fixed-speed fan running at full tilt 24/7. That runtime efficiency difference is what justifies the accessory cost in a continuous-operation data center environment.
Technical Highlights:
- EC Fan Efficiency: EC motors reduce power consumption at partial load compared to fixed-speed AC fans — meaningful in 24/7 runtimes where the fans rarely operate at peak demand.
- iCOM Controls (Factory-Integrated): Factory installation and testing of Liebert iCOM controls eliminates field wiring of the control interface, reducing commissioning time and eliminating a common startup failure point.
- IBC Seismic Certification: Structural bracing is built in — not a field modification — which matters for installations in California or Pacific Northwest facilities where seismic compliance is a permitting requirement, not a preference.
Deployment Considerations:
- Confirm host unit compatibility before ordering — the TPE-29F is designed for specific Vertiv Liebert precision cooling models; not all units accept a top-panel fan assembly without the correct mechanical interface.
- The 115V input is standard, but verify available circuit capacity near the unit — three fans running continuously add to the total amperage draw on the cooling system circuit.
The TPE-29F is the right call for a high-density data room or IDF where the primary precision cooling unit is near its airflow ceiling and you need supplemental top-panel exhaust without installing a second standalone unit.
