Viking Software Special for Item #C2000-B - C2KFBAES

Viking Electronics C2KFBAES Stainless Steel Flush-Mount Faceplate for C2000-B Emergency Phone

Overview

The Viking Electronics C2KFBAES is a heavy-duty stainless steel faceplate and enclosure assembly designed to house the Viking C2000-B emergency phone in demanding indoor and outdoor environments. At 5.0" x 5.0" x 2.25", it installs directly into a standard double-gang electrical box — no custom rough-in required — making it a practical choice for elevator lobbies, parking structures, utility corridors, and anywhere the phone hardware needs serious mechanical protection. If you're specifying Viking Electronics emergency communication systems and need a surface-ready enclosure that meets both aesthetic and environmental standards, the C2KFBAES is the correct finishing component.

Key Features

• 14-Gauge 316 Marine-Grade Stainless Steel Construction: Grade 316 stainless (not the more common 304) adds molybdenum to the alloy, giving it meaningful resistance to chlorides and salt spray. That matters in coastal installations, pool mechanical rooms, or any site where atmospheric corrosion is a real concern — 304 would show surface rust in those environments within months. Laser-etched lettering is integral to the panel, so there's no decal to fade, peel, or become illegible over time.
• IP66 Ingress Protection Rating: IP66 means the enclosure is fully sealed against dust ingress and withstands high-pressure water jets from any direction — rain, spray washdown, and hose-down cleaning routines won't compromise the phone hardware inside. This is the right rating for covered outdoor alcoves and wash-down-capable interior zones. If you need full submersion tolerance, that requires IP67 or higher; the C2KFBAES is rated for jets, not immersion.
• Standard Double-Gang Flush Mount: Designed to land on a standard double-gang electrical box, the C2KFBAES works with the rough-in infrastructure already in most commercial construction projects. No proprietary back-box to spec separately — electricians and low-voltage crews can rough in with standard gear and leave the enclosure installation to the integrator.
• Vandal-Resistant Polycarbonate Strobe Cover: The strobe lens is polycarbonate, not glass — it absorbs impacts that would shatter a glass lens. In high-traffic public areas (transit hubs, parking garages, campus walkways), polycarbonate strobe covers are a maintenance reduction, not just a spec checkbox.
• Stainless Steel Push Button: The call button matches the panel material — stainless steel, not a painted or powder-coated plastic button that chips or corrodes. Consistent material spec across all exposed surfaces means a consistent service life across the assembly.
• Compact 5.0" x 5.0" x 2.25" Profile: The 2.25" depth accommodates the C2000-B hardware within a standard wall cavity. The square footprint keeps the installation unobtrusive in finished wall surfaces without requiring oversized rough-in cutouts.

Compatibility and Integration

The C2KFBAES is engineered specifically as the faceplate and enclosure assembly for the Viking Electronics C2000-B emergency phone. It is not a universal enclosure — confirm the target phone model before ordering. Installation into a standard double-gang electrical box means it integrates cleanly with standard commercial electrical rough-in practices. The IP66 environmental rating makes it compatible with outdoor intercom and emergency communication deployments where direct weather exposure is part of the site design. For projects requiring a complete emergency phone accessory package — mounts, housings, and station hardware — verify the full Viking C2000-B product family to confirm all components.

Frequently Asked Questions

Q: What phone model is the C2KFBAES designed to house?

A: The C2KFBAES is the faceplate and enclosure assembly specifically designed for the Viking Electronics C2000-B emergency phone. It is not a universal enclosure.

Q: What electrical box does the C2KFBAES require for installation?

A: The C2KFBAES is designed to flush-mount into a standard double-gang electrical box — no proprietary or custom back-box is required.

Q: What is the IP66 rating and what environments does it support?

A: IP66 means the enclosure is fully dust-tight and withstands high-pressure water jets from any direction. This makes it suitable for covered outdoor installations, parking structures, and interior zones subject to washdown. It is not rated for submersion — that would require IP67 or higher.

Q: Why is 316 stainless steel specified instead of 304?

A: Grade 316 stainless steel adds molybdenum to its alloy composition, giving it significantly better resistance to chlorides and salt spray compared to 304. This is the correct material spec for coastal environments, pool areas, or any site with elevated atmospheric corrosion risk.

Q: What are the dimensions of the C2KFBAES?

A: The C2KFBAES measures 5.0 inches wide by 5.0 inches tall by 2.25 inches deep.

Eden Phillips

The C2KFBAES uses 14-gauge 316 marine-grade stainless throughout the phone panel — that's a meaningful material upgrade over the 304 stainless you see on most enclosures. For coastal or chemical-wash environments, it's not a cosmetic difference; 316 holds up where 304 develops pitting and surface rust within a season or two.

Technical Highlights:

• IP66 Environmental Seal: Full dust exclusion plus resistance to high-pressure water jets — covers rain, direct spray, and routine washdown without compromising the C2000-B hardware inside.
• 14-Gauge 316 SS Panel: Heavier gauge than the 16- or 18-gauge panels common in budget enclosures; resists denting from impact and long-term surface corrosion in aggressive environments.
• Standard Double-Gang Rough-In: No proprietary back-box means electricians can use standard commercial hardware — cuts both material cost and coordination time on multi-station deployments.

Deployment Considerations:

• Confirm the target phone is specifically the C2000-B before ordering — the C2KFBAES is not a universal Viking enclosure and won't accommodate other models without verification.
• IP66 covers jets and rain, not submersion. For installations at grade level in flood-prone zones or anywhere standing water is possible, verify whether IP67 is required for the site spec.

The C2KFBAES is the right call for coastal transit stations, waterfront facility emergency phones, and marine or pool-complex installations where stainless corrosion resistance and a reliable IP66 seal are non-negotiable site requirements.
