Panduit SFQ 4-PORT MPO-16 FAP/COUPLER - FQMAP4MBL

Panduit FQMAP4MBL Concise Descriptor

Overview

The Panduit FQMAP4MBL is a 4-port MPO-16 Fiber Adapter Panel (FAP) designed for high-density fiber optic network infrastructure. This coupler facilitates the transition from MPO trunk cables to LC or SC connectors within a structured cabling system, ensuring clean and organized fiber termination points. It is engineered for use in enterprise data centers, telecommunication rooms, and high-performance computing environments where maximizing port density and maintaining signal integrity are critical.

Compatibility

This adapter panel is designed to integrate with Panduit's SFQ (Small Form Factor Quick-Connect) fiber optic enclosures and patch panels. It supports MPO-16 (16-fiber) trunk cables and provides 4 duplex LC or SC ports for downstream connections. It is suitable for use with various fiber types, including single-mode (OS2) and multimode (OM3, OM4, OM5) fiber optic cables, provided the connector types match the downstream equipment.

Installation Notes

Proper installation requires careful handling of fiber optic connectors to avoid contamination. Ensure that the MPO trunk cable is correctly keyed and aligned before insertion into the FQMAP4MBL. The panel is designed for tool-less insertion into compatible Panduit SFQ enclosures. Refer to Panduit's installation guides for specific connector mating procedures and environmental handling recommendations.

What's in the Box

• 1x Panduit FQMAP4MBL SFQ 4-PORT MPO-16 FAP/COUPLER
