Vertiv Rpdu Switched Unit Level Monitoring EC 30A 240/415V WYE 17.2KW Vertical (3 - VP5N30AS

Vertiv VP5N30AS Switched 3-Phase Vertical Rack PDU with Outlet-Level Monitoring

Overview

The Vertiv VP5N30AS is a 0U vertical-mount, switched and monitored three-phase rack PDU rated at 30A / 17.2kW on a 240/415V WYE input — built for high-density data center rows and colocation deployments where remote outlet control and real-time power visibility are non-negotiable. With 36 receptacles split across C13 and C19 couplers, it accommodates mixed server and high-draw storage or networking loads in a single vertical unit that keeps the rack U-space fully available for compute. The VP5N30AS supports daisy-chaining, a dual-RJ-45 Ethernet interface, and a full enterprise protocol stack, making it a credible fit for managed data center environments that require per-outlet accountability without a separate monitoring overlay.

Key Features

• Outlet-Level Switching and Monitoring: Each outlet can be individually switched on, off, or rebooted remotely — critical for recovering a hung server in a remote cage without dispatching a technician. Current, voltage, and power are tracked at the unit level, giving ops teams the data to spot overloads before a breaker trips on a live production rack.
• 36 Outlets (C13 + C19 Mix): The combination of C13 and C19 couplers means you can provision standard 1U servers alongside high-draw 2U+ compute or storage nodes on the same PDU, avoiding the mismatch that forces a second PDU just to handle a handful of higher-current devices.
• 30A / 17.2kW Three-Phase Input at 200–415V WYE: The wide input voltage range — 200V to 415V — covers both European 400V three-phase infrastructure and less common international site voltages without a transformer, which simplifies global data center standardization on a single SKU.
• 0U Vertical Form Factor: Installing vertically in the rear of a standard rack eliminates the 1U–2U tax that horizontal PDUs impose. In a 48U rack running at near-full density, that recovered space is real — up to 4U per rack across a large deployment.
• Dual Ethernet (RJ-45) with Daisy-Chain Support: Two RJ-45 ports let you chain multiple PDUs together and manage them through a single IP address, reducing the number of switch ports consumed in a dense row and simplifying DHCP/IP management across many units.
• Enterprise Protocol Stack: SNMP v1/v2c/v3, HTTPS, SSH, LDAP, RADIUS, TACACS+, Modbus TCP, and Syslog are all supported natively. This means the PDU integrates directly into existing DCIM platforms, SIEM pipelines, and AAA infrastructure without a middleware gateway.
• IPv4 and IPv6 with NTP and DHCP: Dual-stack network support future-proofs the unit in environments already migrating to IPv6. NTP synchronization ensures event timestamps in Syslog and SNMP traps are accurate enough to correlate power events with application logs during an incident review.
• LCD Display with Reset Button: The onboard LCD provides a local readout of current draw without requiring a laptop or network connection — useful during initial commissioning or when network access is unavailable. The hardware reset button provides a last-resort recovery path if the management interface becomes unresponsive.
• 3m Power Cord: The included 3-meter cord provides enough reach for most standard rack-to-PDU panel distances without an extension, reducing cable management complexity at the rack base.
• 50/60 Hz Input Frequency: Dual-frequency compatibility means the same unit works in both North American (60 Hz) and international (50 Hz) data center environments, supporting global fleet standardization.

Integration and Compatibility

The VP5N30AS is designed for integration into structured power management environments. Its SNMP v3 support with RADIUS, LDAP, and TACACS+ makes it compatible with enterprise AAA frameworks used in managed colocation and enterprise network infrastructure deployments. Modbus TCP enables integration with building management systems (BMS) that monitor facility-wide power consumption alongside IT loads. For teams running Vertiv ecosystem tools or third-party DCIM platforms, the open protocol approach means the VP5N30AS does not require vendor-specific software to deliver full monitoring and control capability. Syslog output integrates with SIEMs for security-relevant events such as outlet state changes or authentication failures on the management interface.

Frequently Asked Questions

Q: What is the maximum power capacity of the VP5N30AS?

A: The VP5N30AS supports a maximum of 30A at 17.2kW on a three-phase 240/415V WYE input. Actual usable capacity in a balanced three-phase deployment should account for the standard 80% derate, giving a practical continuous load ceiling of approximately 13.8kW.

Q: Can individual outlets on the VP5N30AS be controlled remotely?

A: Yes. The VP5N30AS is a switched PDU, meaning each outlet supports remote on/off/reboot commands via the network management interface. This enables remote server recovery without a physical site visit.

Q: How many PDUs can be daisy-chained together on the VP5N30AS?

A: The VP5N30AS includes daisy-chain support via its dual RJ-45 Ethernet ports, allowing multiple units to be linked and managed under a single IP. The exact chain limit should be confirmed with Vertiv's current firmware documentation, as it may vary by firmware version.

Q: What outlet types does the VP5N30AS provide?

A: The VP5N30AS provides 36 outlets total, using a mix of C13 and C19 IEC coupler types. C13 handles standard 1U server connections; C19 accommodates higher-current devices such as high-density storage arrays or network switches with C20 inlets.

Q: Does the VP5N30AS support SNMP v3?

A: Yes. The VP5N30AS supports SNMP v1, v2c, and v3, along with HTTPS, SSH, LDAP, RADIUS, TACACS+, Modbus TCP, NTP, and Syslog — a complete enterprise protocol stack for managed data center environments.

Q: What input voltage range does the VP5N30AS accept?

A: The VP5N30AS accepts 200–415V AC at 50 or 60 Hz, covering standard European 400V three-phase WYE infrastructure as well as a range of international site voltages without requiring a step-down transformer.

Eden Phillips

The VP5N30AS stands out in the three-phase switched PDU segment specifically because of its 200–415V input range paired with outlet-level switching across all 36 receptacles — that combination is less common than it should be at the 30A/17.2kW tier, and it genuinely simplifies global fleet procurement for organizations with data centers in both North America and Europe.

Technical Highlights:

• 36 Switched Outlets (C13/C19): Mixed coupler types on a single 30A unit remove the common workaround of deploying a secondary PDU just to handle a few high-draw C19 devices — a real cost and cable-management savings in dense rows.
• Dual RJ-45 with Daisy-Chain: Two management ports reduce the IP address and switch port overhead in large rows; chaining PDUs under one IP keeps DCIM inventory clean and simplifies monitoring policy application across many units simultaneously.
• Full Enterprise AAA Stack: RADIUS, LDAP, and TACACS+ support means outlet-level access control integrates into the same identity infrastructure as your servers and network gear — no separate credential silo for power management.

Deployment Considerations:

• In three-phase deployments, plan load balancing across the three phases before outlet assignment. An unbalanced 30A WYE input with all load on one leg will trip the branch circuit well below the 17.2kW nameplate — phase load planning is a commissioning step, not an afterthought.
• The 3m cord is sufficient for most rear-of-rack panel distances, but verify your facility's PDU panel height before ordering — some overhead-busway or raised-floor configurations require a longer whip and a different cord option.

For colocation providers or enterprise IT teams managing multi-continent data center footprints on a standardized platform, the VP5N30AS is a strong fit: the 200–415V WYE input eliminates site-specific SKU splits, and the switched outlet control with SNMP v3 / TACACS+ satisfies the remote-hands-reduction and audit-trail requirements common in managed colo contracts.
