Vertiv Rpdu Switched Outlet Level Monitoring EC 30A 120V 2.8KW Vertical (24) NEMA - VP7N30A5

Vertiv VP7N30A5 Switched Outlet-Level Monitoring PDU, 30A/120V Vertical Rack

Overview

The Vertiv VP7N30A5 is a 0U vertical switched PDU engineered for high-density rack environments where per-outlet power control and real-time monitoring are non-negotiable. Drawing up to 30A at 100–120V (2.8kW) through a NEMA L5-30P input, it distributes power across 24 NEMA 5-20R outlets — enough to densely populate a full rack of 1U servers, storage nodes, or network gear without sacrificing visibility into what each outlet is actually consuming. This is a single-phase unit, so your panel feed stays straightforward, and the vertical 0U form factor means it mounts in the rear channel of the rack without consuming a single rack unit of usable space.

For data center operators, colocation managers, or IT architects managing mixed-density rows, the VP7N30A5 sits at the intersection of switched control and environmental monitoring — giving you remote power cycling on individual outlets alongside current, voltage, power, and temperature readings at the unit level. If you're evaluating the broader Vertiv intelligent PDU line, this model targets the 30A single-phase tier with full outlet-switching capability.

Key Features

• 24 Switched NEMA 5-20R Outlets: Each outlet can be individually toggled on, off, or power-cycled from the network — essential for remotely rebooting a hung server at 3 a.m. without dispatching hands to the data center floor. The 5-20R receptacle format accommodates standard 15A and 20A device plugs interchangeably.
• 30A / 2.8kW Input via NEMA L5-30P: The locking L5-30P plug feeds a 30A circuit, supporting high-density loading. At 2.8kW maximum, you can sustain heavy compute loads across a full rack column — just keep the 80% continuous-load rule (2.24kW) in mind when planning rack layouts. Connect this to rack power distribution infrastructure sized for 30A branch circuits.
• Current, Voltage, Power, and Temperature Monitoring: Real-time telemetry at the inlet level covers all four key parameters. Temperature sensing helps catch hot-aisle / cold-aisle anomalies before they become thermal events. This data feeds directly into your DCIM or monitoring stack via SNMP or Modbus TCP.
• Dual RJ-45 Ethernet Ports: Two network interfaces support daisy-chaining multiple PDUs on a single network drop — reducing switch port consumption and simplifying cabling in multi-PDU rack deployments. No need to run a dedicated Cat cable to every unit in a row.
• Daisy-Chain Support: Chain additional PDUs through the secondary RJ-45 port. This is particularly valuable in colocation or high-density rows where you need to manage 4–6 PDUs per rack without exhausting patch panel ports.
• SNMP v1/v2c/v3 + Modbus TCP: SNMP v3 brings authenticated, encrypted OID polling — a hard requirement in environments under SOC 2, PCI-DSS, or internal security audits. Modbus TCP extends integration options to building management systems (BMS) and industrial SCADA platforms that don't speak SNMP. Both protocols coexist simultaneously.
• Full Enterprise Protocol Suite: LDAP, RADIUS, and TACACS+ mean you can fold the VP7N30A5 into your existing identity infrastructure rather than managing a separate local credential store. SSH secures CLI access; HTTPS secures the web UI. NTP and Syslog round out the operational stack for time-synchronized log correlation.
• IPv4 and IPv6 Dual-Stack: Native IPv6 support future-proofs deployments where data centers are migrating address space or operating in environments with IPv6 mandates (federal, enterprise, carrier).
• LED Display and Indicators: Onboard LED readouts give local visibility into status without requiring a laptop or network connection — useful during initial commissioning or when network access is temporarily unavailable.
• USB Port: The single USB port supports firmware updates, configuration file transfers, or console access depending on the implementation — reducing the need for out-of-band serial adapters.
• Reset Button: Hardware reset capability lets you recover a misconfigured or unresponsive controller without pulling the unit — a small but meaningful operational detail in locked-cabinet environments.
• 3-Meter Input Cord: The 3m (approximately 9.8 ft) input lead provides enough slack to route cleanly from a floor-mounted PDU or overhead busway to the rack's power inlet, accommodating most standard rack depths and raised-floor cable management schemes.

Integration and Compatibility

The VP7N30A5 integrates with DCIM platforms, BMS systems, and network monitoring tools via its broad protocol stack. SNMP v1/v2c/v3 covers the majority of enterprise monitoring platforms — Nagios, SolarWinds, PRTG, Zabbix, and purpose-built DCIM tools like Vertiv's own management software all support SNMP polling. Modbus TCP opens a parallel path to Schneider EcoStruxure, Siemens Desigo, and similar building automation systems that manage power infrastructure alongside HVAC and lighting. LDAP and RADIUS integration ties outlet access control and user authentication into Active Directory or RADIUS servers, which matters when multiple teams share rack access in colocation or enterprise data centers. For environments enforcing role-based access, TACACS+ provides granular command-level authorization on CLI sessions. The dual RJ-45 ports and daisy-chain topology work with standard managed network switches — no proprietary concentrators required. DHCP assignment or static IP configuration is supported for straightforward network integration. Review your data center power planning guide to properly size branch circuits and PDU loading before deployment.

Frequently Asked Questions

Q: Can each outlet on the VP7N30A5 be switched independently?

A: Yes. The VP7N30A5 is a switched outlet-level PDU, meaning each of the 24 NEMA 5-20R outlets can be individually powered on, off, or sequenced remotely over the network. This enables per-device power cycling without affecting adjacent equipment in the rack.

Q: How many PDUs can be daisy-chained together on a single network port?

A: The VP7N30A5 supports daisy-chaining via its dual RJ-45 Ethernet ports. Multiple units can be linked together, allowing management of several PDUs through a single network connection. Consult Vertiv's deployment documentation for the maximum supported chain length in your specific firmware version.

Q: What monitoring parameters does the VP7N30A5 report?

A: The unit monitors current, voltage, power, and temperature at the inlet level and reports these values over SNMP (v1/v2c/v3), Modbus TCP, HTTP/HTTPS, and Syslog — compatible with most DCIM and network monitoring platforms.

Q: Does the VP7N30A5 support SNMP v3 for secure monitoring?

A: Yes. SNMP v3 is supported alongside v1 and v2c. SNMP v3 provides authentication and encryption — required in environments under PCI-DSS, SOC 2, or organizational security policies that prohibit unauthenticated OID polling.

Q: What is the input plug type and what circuit is required?

A: The VP7N30A5 uses a NEMA L5-30P locking plug and requires a 30A, 120V single-phase branch circuit. Per NEC 80% continuous-load guidelines, plan for a maximum sustained load of 2.24kW (approximately 18.7A) to avoid breaker trips under steady-state operation.

Q: Is the VP7N30A5 suitable for IPv6 environments?

A: Yes. The unit supports both IPv4 and IPv6 natively, making it compatible with data centers that have migrated or are migrating to IPv6 addressing — including federal, carrier, and large enterprise environments with IPv6 mandates.

Eden Phillips

When I look at the VP7N30A5, the spec that immediately matters in a high-density deployment is the dual RJ-45 with daisy-chain support — in a 48-outlet-per-rack scenario using two of these units, you consume one switch port instead of two, which sounds minor until you're cabling a 20-rack row. The 24 switched NEMA 5-20R outlets per unit handle the full mix of 15A and 20A server and storage plugs without requiring dedicated 20A-only receptacle banks.

Technical Highlights:

• Outlet-Level Switching (24 outlets): Individual on/off/reboot per outlet over SNMP or web UI — eliminates the need for separate remote console servers or smart KVM for basic device recovery tasks.
• SNMP v3 + Modbus TCP Coexistence: Running both simultaneously means one PDU can simultaneously report to a network NOC via SNMP v3 (encrypted) and to a BMS via Modbus TCP — no protocol bridging appliance required.
• 30A L5-30P Input / 2.8kW: Sized for the 30A branch circuit tier common in purpose-built data center rooms; the locking plug eliminates accidental disconnection in vibration-prone environments like raised-floor spaces with active cooling equipment.

Deployment Considerations:

• The 80% continuous-load rule caps real-world sustained draw at roughly 2.24kW / 18.7A — plan rack loads accordingly before committing to a single 30A feed per column, especially if adding dense GPU or storage nodes later.
• LDAP/RADIUS/TACACS+ authentication requires pre-configured directory entries; budget time for identity integration during commissioning — it's not plug-and-play against all AD schemas without specific attribute mappings.

The VP7N30A5 is the right call for colocation operators and enterprise data center teams managing mixed-density racks where remote outlet-level reboot capability and multi-protocol monitoring (SNMP v3 to the NOC, Modbus TCP to the BMS) need to coexist on a single vertical 0U unit without consuming rack space.
