Mains Power Consumption:
120 VAC, 45 volt-amps
Frequency Response:
50Hz to 16kHz
Signal-To-Noise Ratio:
58 dB
Dimensions:
1.72” high, 19” wide, 15.6” deep
Total Harmonic Distortion:
0.2%
Weight:
10.4 lbs.
Nominal Input Level:
-15 dBu to -5 dBu
Microphone Supplied Power:
32 VDC nominal
Microphone Current Draw:
50 to 80 mA
Line Dimensions:
5” high, 3.5” wide, 1.8” deep
Microphone Input Impedance:
470 Ω
Line Input Impedance:
4.7k Ω
Line Weight:
1.0 lbs
Storage Temperature:
-WC to 80T
Storage Humidity:
0% to 95%
Operating Temperature:
PC to 50T
Operating Humidity:
0% to 95%
Gain:
54 dB to 14 dB
Nominal Output Level:
-10 dBu, balanced
Headphone Impedance:
150 to 600½
RTS Intercom Channel Voltage:
14 VAC
RTS Intercom Channel Current:
200 mA
Input Level:
2 Vpp (0 dBu) nominal
Input Impedance:
200½ ±5%
Noise Contribution:
Less than -60 dB
Voltage Gain:
27 ±3 dB
Maximum Output:
165 mW into 150½
Headset Connector Type:
¼” Monaural Plug
Intercom Channel Connectors:
XLR-3F
Interrupt Channel:
-73 dBu
Non-interrupt Channel:
-83 dBu
Power Consumption:
150mA maximum
4030 Dimensions:
5” high, 3.5” wide, 1.8” deep
4030 Weight:
0.67 lb
Microphone Input Level:
-10 dBu/input
Earset Input Level:
0 dBu/input
Nominal Output Level To User Stations:
-8 dBu/unbalanced
Nominal Output Level To SA amplifier:
-5 dBu/balanced
Crosstalk:
-67 dBu
Crosstalk Between Channels:
-64 dBu
